11TE | pdb_000011te

Crystal Structure of ATP phosphoribosyltransferase from Bordetella pertussis

• PDB DOI: https://doi.org/10.2210/pdb11TE/pdb

• Classification: TRANSFERASE
• Organism(s): Bordetella pertussis Tohama I
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2026-03-12 Released: 2026-03-25
• Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)
• Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:
  0.219 (Depositor), 0.224 (DCC)
• R-Value Work:
  0.193 (Depositor), 0.202 (DCC)
• R-Value Observed:
  0.195 (Depositor)

Starting Model: in silico

Literature

Crystal Structure of ATP phosphoribosyltransferase from Bordetella pertussis

Ung, A.R., Lovell, S., Cooper, A., Battaile, K.P.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 2 generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 25.02 kDa
• Atom Count: 1,716
• Modeled Residue Count: 210
• Deposited Residue Count: 227
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ATP phosphoribosyltransferase	A	227	Bordetella pertussis Tohama I	Mutation(s): 0  Gene Names: hisG, BP3767 EC: 2.4.2.17
UniProt
Find proteins for Q7VSZ2 (Bordetella pertussis (strain Tohama I / ATCC BAA-589 / NCTC 13251)) Explore Q7VSZ2  Go to UniProtKB:  Q7VSZ2

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
SO4 (Subject of Investigation/LOI)	B [auth A], C [auth A], D [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
GOL	F [auth A]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL	E [auth A]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.55 Å
• R-Value Free:  0.219 (Depositor), 0.224 (DCC)
• R-Value Work:  0.193 (Depositor), 0.202 (DCC)
• R-Value Observed: 0.195 (Depositor)

Diffraction Data: https://doi.org/10.18430/M311TE

Space Group: P 4₁ 2₁ 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 83.269	α = 90
b = 83.269	β = 90
c = 63.77	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2026-03-25
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease (SSGCID)

---

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394

Revision History

• Version 1.0: 2026-03-25
  Type: Initial release
