2QQ4 | pdb_00002qq4

Crystal structure of Iron-sulfur cluster biosynthesis protein IscU (TTHA1736) from thermus thermophilus HB8

• PDB DOI: https://doi.org/10.2210/pdb2QQ4/pdb

• Classification: METAL BINDING PROTEIN
• Organism(s): Thermus thermophilus
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-07-26 Released: 2008-07-29
• Deposition Author(s): Jeyakanthan, J., Kanaujia, S.P., Sekar, K., Agari, Y., Ebihara, A., Shinkai, A., Kuramitsu, S., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:
  0.260 (Depositor), 0.260 (DCC)
• R-Value Work:
  0.225 (Depositor), 0.230 (DCC)
• R-Value Observed:
  0.225 (Depositor)

Starting Model: experimental

Literature

Crystal structure of Iron-sulfur cluster biosynthesis protein IscU (TTHA1736) from thermus thermophilus HB8

Jeyakanthan, J., Kanaujia, S.P., Sekar, K., Agari, Y., Ebihara, A., Shinkai, A., Kuramitsu, S., Yokoyama, S.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C5  (Explore in 3D)
Global Stoichiometry: Homo 5-mer - A5

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly 2

Global Symmetry: Cyclic - C5  (Explore in 3D)
Global Stoichiometry: Homo 5-mer - A5

Biological assembly 2 assigned by authors and generated by PISA (software)

Macromolecule Content

• Total Structure Weight: 148.59 kDa
• Atom Count: 11,013
• Modelled Residue Count: 1,369
• Deposited Residue Count: 1,380
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Iron-sulfur cluster biosynthesis protein IscU	A, B, C, D, E, F, G, H, I, J	138	Thermus thermophilus	Mutation(s): 0
UniProt
Find proteins for Q5SHJ4 (Thermus thermophilus (strain ATCC 27634 / DSM 579 / HB8)) Explore Q5SHJ4  Go to UniProtKB:  Q5SHJ4

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
ZN	K [auth A], L [auth B], M [auth C], N [auth D], O [auth E], P [auth F], Q [auth G], R [auth H], S [auth I], T [auth J]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.85 Å
• R-Value Free:  0.260 (Depositor), 0.260 (DCC)
• R-Value Work:  0.225 (Depositor), 0.230 (DCC)
• R-Value Observed: 0.225 (Depositor)

Space Group: P 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 58.886	α = 71.18
b = 64.866	β = 78.96
c = 96.26	γ = 79.02

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data collection
HKL-2000	data reduction
SCALEPACK	data scaling
MOLREP	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-07-29
Deposition Author(s): Jeyakanthan, J., Kanaujia, S.P., Sekar, K., Agari, Y., Ebihara, A., Shinkai, A., Kuramitsu, S., Yokoyama, S., RIKEN Structural Genomics/Proteomics Initiative (RSGI)

Revision History

• Version 1.0: 2008-07-29
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Version format compliance
• Version 1.2: 2017-10-25
  Changes: Refinement description
• Version 1.3: 2023-10-25
  Changes: Data collection, Database references, Derived calculations, Refinement description
