2FO1

Crystal Structure of the CSL-Notch-Mastermind ternary complex bound to DNA


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.12 Å
  • R-Value Free: 0.340
  • R-Value Work: 0.273
  • R-Value Observed: 0.273

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.5 of the entry. See complete history


Literature

Crystal structure of the CSL-Notch-Mastermind ternary complex bound to DNA.

Wilson, J.J.Kovall, R.A.

(2006) Cell 124: 985-996

  • DOI: https://doi.org/10.1016/j.cell.2006.01.035
  • Primary Citation of Related Structures:
    2FO1

  • PubMed Abstract:

    Notch signaling mediates communication between cells and is essential for proper embryonic patterning and development. CSL is a DNA binding transcription factor that regulates transcription of Notch target genes by interacting with coregulators. Transcriptional activation requires the displacement of corepressors from CSL by the intracellular portion of the receptor Notch (NotchIC) and the recruitment of the coactivator protein Mastermind to the complex. Here we report the 3.1 A structure of the ternary complex formed by CSL, NotchIC, and Mastermind bound to DNA. As expected, the RAM domain of Notch interacts with the beta trefoil domain of CSL; however, the C-terminal domain of CSL has an unanticipated central role in the interface formed with the Notch ankyrin repeats and Mastermind. Ternary complex formation induces a substantial conformational change within CSL, suggesting a molecular mechanism for the conversion of CSL from a repressor to an activator.


  • Organizational Affiliation

    Department of Molecular Genetics, Biochemistry, and Microbiology, University of Cincinnati College of Medicine, Cincinnati, OH 45267, USA.


Macromolecules

Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Lin-12 and glp-1 phenotype protein 1, isoform bC [auth A]477Caenorhabditis elegansMutation(s): 0
Gene Names: LAG-1
UniProt
Find proteins for V6CLJ5 (Caenorhabditis elegans)
Explore V6CLJ5
Go to UniProtKB:  V6CLJ5
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupV6CLJ5
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 4
MoleculeChains Sequence LengthOrganismDetailsImage
Protein lag-385Caenorhabditis elegansMutation(s): 0
Gene Names: sel-8lag-3
UniProt
Find proteins for Q09260 (Caenorhabditis elegans)
Explore Q09260
Go to UniProtKB:  Q09260
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ09260
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 5
MoleculeChains Sequence LengthOrganismDetailsImage
Lin-12 protein373Caenorhabditis elegansMutation(s): 14
Gene Names: lin-12
UniProt
Find proteins for P14585 (Caenorhabditis elegans)
Explore P14585
Go to UniProtKB:  P14585
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14585
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 1
MoleculeChains LengthOrganismImage
5'-D(*TP*TP*AP*CP*TP*GP*TP*GP*GP*GP*AP*AP*AP*GP*A)-3'A [auth B]15N/A
Sequence Annotations
Expand
  • Reference Sequence

Find similar nucleic acids by:  Sequence   |   3D Structure

Entity ID: 2
MoleculeChains LengthOrganismImage
5'-D(*AP*AP*TP*CP*TP*TP*TP*CP*CP*CP*AP*CP*AP*GP*T)-3'B [auth C]15N/A
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  1 Unique
IDChains TypeFormula2D DiagramParent
MSE
Query on MSE
E
L-PEPTIDE LINKINGC5 H11 N O2 SeMET
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 3.12 Å
  • R-Value Free: 0.340
  • R-Value Work: 0.273
  • R-Value Observed: 0.273
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 66.093α = 90
b = 96.785β = 90
c = 243.538γ = 90
Software Package:
Software NamePurpose
CNSrefinement
HKL-2000data reduction
SCALEPACKdata scaling
SHARPphasing

Structure Validation

View Full Validation Report



Entry History

Deposition Data

Revision History  (Full details and data files)

  • Version 1.0: 2006-03-21
    Type: Initial release
  • Version 1.1: 2008-05-01
    Changes: Version format compliance
  • Version 1.2: 2011-07-13
    Changes: Version format compliance
  • Version 1.3: 2023-08-30
    Changes: Data collection, Database references, Derived calculations, Refinement description
  • Version 1.4: 2023-11-15
    Changes: Data collection
  • Version 1.5: 2024-11-20
    Changes: Structure summary
