2E8Z

Crystal structure of pullulanase type I from Bacillus subtilis str. 168 complexed with alpha-cyclodextrin

• PDB DOI: https://doi.org/10.2210/pdb2E8Z/pdb

• Classification: HYDROLASE
• Organism(s): Bacillus subtilis
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2007-01-24 Released: 2008-02-19
• Deposition Author(s): Mikami, B., Malle, D., Utsumi, S., Iwamoto, H., Katsuya, Y.

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free: 0.237
• R-Value Work: 0.196
• R-Value Observed: 0.196

Starting Model: experimental

Literature

Crystal structure of pullulanase type I from Bacillus subtilis str. 168 in complex with maltose and alpha-cyclodextrin

Malle, D., Iwamoto, H., Katsuya, Y., Utsumi, S., Mikami, B.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Macromolecule Content

• Total Structure Weight: 164.78 kDa
• Atom Count: 12,165
• Modelled Residue Count: 1,424
• Deposited Residue Count: 1,436
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
AmyX protein	A, B	718	Bacillus subtilis	Mutation(s): 0  Gene Names: amyX EC: 3.2.1.41
UniProt
Find proteins for C0SPA0 (Bacillus subtilis (strain 168)) Explore C0SPA0  Go to UniProtKB:  C0SPA0

Oligosaccharides

Help

Entity ID: 2
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
Cyclohexakis-(1-4)-(alpha-D-glucopyranose)	C, D	6		N/A
Glycosylation Resources
GlyTouCan:  G22307HL GlyCosmos:  G22307HL

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
GOL	G [auth A], J [auth B]	GLYCEROL C3 H8 O3 PEDCQBHIVMGVHV-UHFFFAOYSA-N
ACT	F [auth A], I [auth B]	ACETATE ION C2 H3 O2 QTBSBXVTEAMEQO-UHFFFAOYSA-M
CA	E [auth A], H [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N

Biologically Interesting Molecules (External Reference) 1 Unique

Entity ID: 2
ID	Chains	Name	Type/Class	2D Diagram	3D Interactions
PRD_900015	C, D	alpha-cyclodextrin	Oligosaccharide / Drug delivery

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.20 Å
• R-Value Free: 0.237
• R-Value Work: 0.196
• R-Value Observed: 0.196
• Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 70.327	α = 90
b = 127.78	β = 90
c = 189.274	γ = 90

Software Package:

Software Name	Purpose
CNS	refinement
HKL-2000	data collection
HKL-2000	data reduction
HKL-2000	data scaling
CNS	phasing

Structure Validation

Entry History

Deposition Data

• Released Date: 2008-02-19
Deposition Author(s): Mikami, B., Malle, D., Utsumi, S., Iwamoto, H., Katsuya, Y.

Revision History

• Version 1.0: 2008-02-19
  Type: Initial release

• Version 1.1: 2011-07-13
  Changes: Non-polymer description, Version format compliance
• Version 2.0: 2020-07-29
  Type: Remediation
  Reason: Carbohydrate remediation
  Changes: Atomic model, Data collection, Database references, Derived calculations, Structure summary
• Version 2.1: 2023-10-25
  Changes: Data collection, Database references, Refinement description, Structure summary
