9Z2Y | pdb_00009z2y

Crystal structure of Glutamate-tRNA synthetase GluRS from Chlamydia pneumoniae in complex with ATP

PDB DOI: https://doi.org/10.2210/pdb9Z2Y/pdb

Classification: LIGASE
Organism(s): Chlamydia pneumoniae
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-11-05 Released: 2025-11-26
Deposition Author(s): Seattle Structural Genomics Center for Infectious Disease, Seattle Structural Genomics Center for Infectious Disease (SSGCID)
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID), National Institutes of Health/Office of the Director

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.65 Å
R-Value Free:
0.264 (Depositor), 0.260 (DCC)
R-Value Work:
0.211 (Depositor), 0.212 (DCC)
R-Value Observed:
0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of Glutamate-tRNA synthetase GluRS from Chlamydia pneumoniae in complex with ATP

Liu, L., Lovell, S., Battaile, K.P.

To be published.

Macromolecule Content

Total Structure Weight: 122.29 kDa
Atom Count: 7,709
Modeled Residue Count: 950
Deposited Residue Count: 1,052
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Glutamate--tRNA ligase	A, B	526	Chlamydia pneumoniae	Mutation(s): 0 Gene Names: gltX, CPn_0560, CP_0190, CpB0582 EC: 6.1.1.17
UniProt
Find proteins for Q9Z7Z3 (Chlamydia pneumoniae) Explore Q9Z7Z3 Go to UniProtKB: Q9Z7Z3
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q9Z7Z3
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ATP (Subject of Investigation/LOI) Query on ATP Download Ideal Coordinates CCD File SDF format, chain F [auth B] MOL2 format, chain F [auth B] mmCIF format, chain F [auth B]	F [auth B]	ADENOSINE-5'-TRIPHOSPHATE C₁₀ H₁₆ N₅ O₁₃ P₃ ZKHQWZAMYRWXGA-KQYNXXCUSA-N		Interactions Focus chain F [auth B] Interactions & Density Focus chain F [auth B]
SO4 Query on SO4 Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain G [auth B] SDF format, chain H [auth B] SDF format, chain I [auth B] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain G [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain G [auth B] mmCIF format, chain H [auth B] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B]	C [auth A] D [auth A] G [auth B] H [auth B] I [auth B] C [auth A], D [auth A], G [auth B], H [auth B], I [auth B], J [auth B]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B]
CL Query on CL Download Ideal Coordinates CCD File SDF format, chain K [auth B] SDF format, chain E [auth A] MOL2 format, chain K [auth B] MOL2 format, chain E [auth A] mmCIF format, chain K [auth B] mmCIF format, chain E [auth A]	E [auth A], K [auth B]	CHLORIDE ION Cl VEXZGXHMUGYJMC-UHFFFAOYSA-M		Interactions Focus chain E [auth A] Focus chain K [auth B] Interactions & Density Focus chain E [auth A] Focus chain K [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.65 Å
R-Value Free: 0.264 (Depositor), 0.260 (DCC)
R-Value Work: 0.211 (Depositor), 0.212 (DCC)
R-Value Observed: 0.214 (Depositor)

Diffraction Data: https://doi.org/10.18430/M39Z2Y

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 49.946	α = 90
b = 132.078	β = 104.23
c = 92.34	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Aimless	data scaling
XDS	data reduction
PHASER	phasing
PDB_EXTRACT	data extraction

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-11-26

Deposition Author(s):

Seattle Structural Genomics Center for Infectious Disease

Seattle Structural Genomics Center for Infectious Disease (SSGCID)

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	75N93022C00036
National Institutes of Health/Office of the Director	United States	S10OD030394
