9YVV | pdb_00009yvv

Cocrystallized structure of Bmp7 in complex with 2,4-dibromophenol


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.32 Å
  • R-Value Free:
    0.230 (Depositor), 0.230 (DCC)
  • R-Value Work:
    0.193 (Depositor), 0.192 (DCC)
  • R-Value Observed:
    0.195 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Bacterial cytochrome P450 for oxidative halogenated biaryl coupling.

Petriti, V.Nolan, K.Xu, W.Tsai, S.Wang, X.Xie, W.J.Zheng, G.Wang, Y.Ding, Y.

(2026) ACS Catal 16: 2615-2627

  • DOI: https://doi.org/10.1021/acscatal.5c08060
  • Primary Citation Related Structures:
    9MS3, 9YV5, 9YVV

  • PubMed Abstract:

    Biaryl motifs are fundamental structural elements in many pharmaceuticals, agrochemicals, and advanced materials. Traditional synthetic approaches for biaryl bond formation often require harsh conditions, costly catalysts, and pre-functionalized starting materials, which limit their efficiency, sustainability, and substrate scope. Enzymatic catalysis offers a greener alternative. However, biocatalysts capable of directly coupling halogenated biaryl compounds remain largely underexplored. Here, we report the functional characterization of the marine-derived cytochrome P450 enzyme Bmp7, which catalyzes the formation of halogenated biaryls. We first characterized the product profile of recombinant Bmp7 using its native substrate 2,4-dibromophenol ( 1 ) and confirmed the dominant ortho - ortho C-C homocoupled product as MC21-A. Screening a halogenated aromatic substrate library revealed that Bmp7 binds and catalyzes the coupling of 17 halogenated phenols, as evidenced by spectral shift assays, LC-HRMS, HRMS/MS and GC-MS analyses. Two homocoupled products were structurally confirmed by NMR analysis to possess ortho-ortho C-C linkages. In addition to efficient homocoupling, Bmp7 catalyzed heterocoupling reactions between substrate 1 and 16 other substrates, producing mixtures of homocoupled and heterocoupled halogenated biphenols. X-ray crystallography revealed the binding of two substrate 1 molecules within the active site, while DFT calculations supported a single-radical reaction mechanism, shedding light on the mechanistic basis of the coupling reaction. Together, these findings lay the groundwork for these findings establish a foundation for future efforts in enzyme engineering and the development of biocatalytic strategies for synthetic applications.


  • Organizational Affiliation
    • Department of Medicinal Chemistry, Center for Natural Products, Drug Discovery and Development, University of Florida, Gainesville, FL, 32610 USA.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Polybrominated aromatic compounds synthase495Marinomonas mediterraneaMutation(s): 0
Gene Names: bmp7Marme_4095
EC: 1.14.19
UniProt
Find proteins for F2K081 (Marinomonas mediterranea (strain ATCC 700492 / JCM 21426 / NBRC 103028 / MMB-1))
Explore F2K081
Go to UniProtKB:  F2K081
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupF2K081
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 4 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
HEM (Subject of Investigation/LOI)
Query on HEM

Download Ideal Coordinates CCD File
F [auth A]PROTOPORPHYRIN IX CONTAINING FE
C34 H32 Fe N4 O4
KABFMIBPWCXCRK-RGGAHWMASA-L
Y8I (Subject of Investigation/LOI)
Query on Y8I

Download Ideal Coordinates CCD File
G [auth A],
H [auth A]
2,4-bis(bromanyl)phenol
C6 H4 Br2 O
FAXWFCTVSHEODL-UHFFFAOYSA-N
GOL
Query on GOL

Download Ideal Coordinates CCD File
B [auth A],
C [auth A],
D [auth A]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
CL
Query on CL

Download Ideal Coordinates CCD File
E [auth A]CHLORIDE ION
Cl
VEXZGXHMUGYJMC-UHFFFAOYSA-M
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.32 Å
  • R-Value Free:  0.230 (Depositor), 0.230 (DCC)
  • R-Value Work:  0.193 (Depositor), 0.192 (DCC)
  • R-Value Observed: 0.195 (Depositor)
Space Group: P 32 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 101.22α = 90
b = 101.22β = 90
c = 159.924γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
SCALEPACKdata scaling
DENZOdata reduction
PHENIXphasing
PDB_EXTRACTdata extraction

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35GM147510
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)United StatesR35GM128742

Revision History  (Full details and data files)

  • Version 1.0: 2026-01-07
    Type: Initial release
  • Version 1.1: 2026-03-18
    Changes: Database references
