9YJW | pdb_00009yjw

Transferrin Binding Protein A

PDB DOI: https://doi.org/10.2210/pdb9YJW/pdb
EM Map EMD-73037: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Neisseria meningitidis serogroup B
Expression System: Escherichia coli 0.1197
Mutation(s): No

Deposited: 2025-10-05 Released: 2026-03-04
Deposition Author(s): Dubey, S., Noinaj, N.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 4.20 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9YJW

This is version 1.0 of the entry. See complete history.

Literature

Transferrin Binding Protein A in complex with transferrin (iron bound in N lobe only)

Dubey, S., Noinaj, N.

To be published.

Macromolecule Content

Total Structure Weight: 102.51 kDa
Atom Count: 6,609
Modeled Residue Count: 842
Deposited Residue Count: 915
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Transferrin-binding protein A	A	915	Neisseria meningitidis serogroup B	Mutation(s): 0 Gene Names: tbpA
UniProt
Find proteins for Q9JPJ0 (Neisseria meningitidis) Explore Q9JPJ0 Go to UniProtKB: Q9JPJ0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9JPJ0
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 4.20 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-03-04

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	1R01AI127793

Revision History (Full details and data files)

Version 1.0: 2026-03-04
Type: Initial release
