9YC8 | pdb_00009yc8

Leucine Rich Repeat Kinase 2 activate state (Apo ROC state 1)

PDB DOI: https://doi.org/10.2210/pdb9YC8/pdb
EM Map EMD-72762: EMDB EMDataResource

Classification: HYDROLASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2025-09-18 Released: 2026-08-19
Deposition Author(s): Villagran Suarez, A., Bodrug, T., Leschziner, A.
Funding Organization(s): Aligning Science Across Parkinsons (ASAP)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 4.02 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9YC8

This is version 1.0 of the entry. See complete history.

Literature

The structural basis for LRRK2's activation and autoinhibition

Villagran Suarez, A., Hatch, K.S., Bodrug, T., Gai, W., Surridge, K.J., Moussikhina, E., Nguyen, K.H., Sanz-Murillo, M., Callahan, R., Xiong, E., Ramos, D., Zhu, L., Dederer, V., Mathea, S., Iwasa, J., Knapp, S., Shokat, K.M., Reck-Peterson, S.L., Leschziner, A.E.

(2026) Cell

DOI: https://doi.org/10.1016/j.cell.2026.07.027

Macromolecule Content

Total Structure Weight: 286.49 kDa
Atom Count: 7,822
Modeled Residue Count: 1,051
Deposited Residue Count: 2,527
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Leucine-rich repeat serine/threonine-protein kinase 2	A [auth B]	2,527	Homo sapiens	Mutation(s): 0 Gene Names: LRRK2 EC: 2.7.11.1 (UniProt), 3.6.5 (UniProt)
UniProt & NIH Common Fund Data Resources
Find proteins for Q5S007 (Homo sapiens) Explore Q5S007 Go to UniProtKB: Q5S007
GTEx: ENSG00000188906
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q5S007
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
MG Query on MG Download:Ideal Coordinates CCD File SDF format, chain B MOL2 format, chain B mmCIF format, chain B	B	MAGNESIUM ION Mg JLVVSXFLKOJNIY-UHFFFAOYSA-N		Interactions Focus chain B Interactions & Density Focus chain B

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 4.02 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-08-19

Deposition Author(s):

Villagran Suarez, A.

Funding Organization	Location	Grant Number
Aligning Science Across Parkinsons (ASAP)	United States	--

Revision History (Full details and data files)

Version 1.0: 2026-08-19
Type: Initial release
