9X30 | pdb_00009x30

Cryo-EM structure of R. castenholzii ModBC in the resting state.

PDB DOI: https://doi.org/10.2210/pdb9X30/pdb
EM Map EMD-66489: EMDB EMDataResource

Classification: TRANSPORT PROTEIN
Organism(s): Roseiflexus castenholzii DSM 13941
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2025-10-08 Released: 2026-10-28
Deposition Author(s): Wu, W., Xu, X.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.32 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9X30

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of R. castenholzii ModBC in the resting state.

Wu, W., Xu, X.

To be published.

Macromolecule Content

Total Structure Weight: 138.89 kDa
Atom Count: 8,676
Modeled Residue Count: 1,110
Deposited Residue Count: 1,260
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Molybdenum transport system permease	A, B	257	Roseiflexus castenholzii DSM 13941	Mutation(s): 0 Gene Names: Rcas_2177
UniProt
Find proteins for A7NL88 (Roseiflexus castenholzii (strain DSM 13941 / HLO8)) Explore A7NL88 Go to UniProtKB: A7NL88
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A7NL88
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
ABC transporter related	C, D	373	Roseiflexus castenholzii DSM 13941	Mutation(s): 0 Gene Names: Rcas_2176
UniProt
Find proteins for A7NL87 (Roseiflexus castenholzii (strain DSM 13941 / HLO8)) Explore A7NL87 Go to UniProtKB: A7NL87
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A7NL87
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.32 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487
RECONSTRUCTION	cryoSPARC	v3.3.2

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-10-28

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32171227
National Natural Science Foundation of China (NSFC)	China	82101628

Revision History (Full details and data files)

Version 1.0: 2026-10-28
Type: Initial release
