9WIY | pdb_00009wiy

Apg mutant enzyme D336A of the human gut flora K. grimontii TD1 acarbose hydrolas

PDB DOI: https://doi.org/10.2210/pdb9WIY/pdb

Classification: HYDROLASE
Organism(s): Klebsiella grimontii
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2025-08-30 Released: 2026-09-02
Deposition Author(s): Zhou, J.H., Huang, J.Y.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.43 Å
R-Value Free:
0.229 (Depositor), 0.229 (DCC)
R-Value Work:
0.187 (Depositor), 0.188 (DCC)
R-Value Observed:
0.189 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9WIY

This is version 1.0 of the entry. See complete history.

Literature

Apg mutant enzyme D336A of the human gut flora K. grimontii TD1 acarbose hydrolas

Zhou, J.H., Huang, J.Y.

To be published.

Macromolecule Content

Total Structure Weight: 69.06 kDa
Atom Count: 5,057
Modeled Residue Count: 600
Deposited Residue Count: 605
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Maltodextrin glucosidase	A	605	Klebsiella grimontii	Mutation(s): 1 Gene Names: tvaI, malZ, HV064_03130, NCTC9149_05459 EC: 3.2.1.135 (PDB Primary Data), 3.2.1.20 (PDB Primary Data)
UniProt
Find proteins for A0A7H4P971 (Klebsiella grimontii) Explore A0A7H4P971 Go to UniProtKB: A0A7H4P971
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A7H4P971
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.43 Å
R-Value Free: 0.229 (Depositor), 0.229 (DCC)
R-Value Work: 0.187 (Depositor), 0.188 (DCC)
R-Value Observed: 0.189 (Depositor)

Space Group: P 6₅ 2 2

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 75.778	α = 90
b = 75.778	β = 90
c = 402.783	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
PHENIX	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-09-02

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-09-02
Type: Initial release
