9WB3 | pdb_00009wb3

HRV14 3C in complex with single chain antibody YDF and cloverleafRNA-conformation1-composite-1

PDB DOI: https://doi.org/10.2210/pdb9WB3/pdb
EM Map EMD-65832: EMDB EMDataResource

Classification: RNA BINDING PROTEIN/RNA/IMMUNE SYSTEM
Organism(s): rhinovirus B14, Homo sapiens
Expression System: Escherichia coli BL21
Mutation(s): No

Deposited: 2025-08-13 Released: 2026-03-25
Deposition Author(s): Wang, Q.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.17 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

HRV14 3C in complex with single chain antibody YDF and cloverleafRNA-conformation1-composite-1

Wang, Q.

To be published.

Macromolecule Content

Total Structure Weight: 71.33 kDa
Atom Count: 4,722
Modeled Residue Count: 486
Deposited Residue Count: 495
Unique protein chains: 3
Unique nucleic acid chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Protease 3C	A	180	rhinovirus B14	Mutation(s): 0 EC: 3.4.22.28
UniProt
Find proteins for P03303 (Human rhinovirus 14) Explore P03303 Go to UniProtKB: P03303
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P03303
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
YDF heavy chain	B	127	Homo sapiens	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
YDF light chain	C	105	Homo sapiens	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by:

(by identity cutoff)

Entity ID: 4
Molecule	Chains	Length	Organism	Image
RNA (83-MER)	D [auth R]	83	rhinovirus B14
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.17 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2026-03-25

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2026-03-25
Type: Initial release
