 9W4L | pdb_00009w4l

Cryo-EM structure of inhibitor M353-0039 bound urea transporter A2.


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.70 Å
  • Aggregation State: CELL
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9W4L

This is version 1.0 of the entry. See complete history.

Literature

Hotspot pocket-based discovery of urea transporter selective inhibitors.

Liu, L., Li, Z., Zhang, C., Zhang, Y., Huang, Z., Zhang, D., Li, D., Zhao, J., Miao, Y., Cai, B., Zhu, K., Sun, J.P., Hou, G., Sun, Y., Yang, B., Yu, X., Huang, S.

(2026) Nat Commun 17

  • DOI: https://doi.org/10.1038/s41467-026-71834-w
  • Primary Citation Related Structures:
    9W4K, 9W4L

  • PubMed Abstract:

    Urea transporter (UT) inhibitors are a promising class of diuretics, as selective inhibitors targeting UT-A subtypes have demonstrated considerable therapeutic potential. Herein, we employ a two-round progressive hotspot pocket-based virtual screening approach combined with biological validation to identify M353-0039 as a highly potent and selective inhibitor of UT-A2. We conduct cryo-electron microscopy to solve the structures of UT-A2 bound with the two inhibitors, M353-0039 and E822-1968, at the resolution of 2.7 Å and 2.9 Å respectively, and elucidate the structural mechanism underlying the superior efficacy and selectivity of M353-0039. Compared with the inhibitor HQA2 and E822-1968, M353-0039 occupies a deeper binding pocket and forms more interactions with UT-A2, thus leading to greater inhibitory potency. We demonstrate that the selectivity of M353-0039 is driven by the nonconserved residues C285 and G322 within the "T-T" subpocket of UT-A2. Finally, we validate the selective effects of M353-0039 in inhibiting UT-A2 function both in mouse models and hepatic cell. These findings not only identify a selective inhibitor as a tool that can be applied to elucidate the unique physiological roles of UT-A2 but also provide an available method for efficiently developing UT-A-selective inhibitors with potent activity as the next-generation diuretics.


  • Organizational Affiliation:
    • State Key Laboratory of Bioactive Molecules and Druggability Assessment, Guangdong Basic Research Center of Excellence for Natural Bioactive Molecules and Discovery of Innovative Drugs, Jinan University, Guangzhou, China.

Macromolecule Content

  • Total Structure Weight: 131.34 kDa
  • Atom Count: 7,632
  • Modeled Residue Count: 990
  • Deposited Residue Count: 1,191
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Urea transporter 2
A, B, C
397Homo sapiensMutation(s): 0
Gene Names: SLC14A2, HUT2, UT2
UniProt & NIH Common Fund Data Resources
Find proteins for Q15849 (Homo sapiens)
Explore Q15849
Go to UniProtKB:  Q15849
PHAROS:  Q15849
GTEx:  ENSG00000132874
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ15849
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.70 Å
  • Aggregation State: CELL
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China82304601

Revision History  (Full details and data files)

  • Version 1.0: 2026-08-05
    Type: Initial release
