9W3W | pdb_00009w3w

Structure of Csm6 from Actinomyces procaprae in complex with cyclic penta-adenylate

PDB DOI: https://doi.org/10.2210/pdb9W3W/pdb
EM Map EMD-65611: EMDB EMDataResource

Classification: IMMUNE SYSTEM/RNA
Organism(s): Actinomyces procaprae
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-07-30 Released: 2026-03-04
Deposition Author(s): Lin, Z., Gao, H., Shi, R., Yang, M., Liu, Y.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.67 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Structure of Csm6 from Actinomyces procaprae in complex with cyclic penta-adenylate

Lin, Z., Gao, H., Shi, R., Yang, M., Liu, Y.

To be published.

Macromolecule Content

Total Structure Weight: 348.29 kDa
Atom Count: 24,048
Modeled Residue Count: 3,152
Deposited Residue Count: 3,208
Unique protein chains: 1
Unique nucleic acid chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Csm6	E [auth A], F [auth B], G [auth C], H [auth D]	797	Actinomyces procaprae	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Entity ID: 1
Molecule	Chains	Length	Organism	Image
RNA (5'-R(PAPAPAPAP*A)-3')	A [auth 1], B [auth 2], C [auth 3], D [auth 4]	5	Actinomyces procaprae
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.67 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419:
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2026-03-04

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2026-03-04
Type: Initial release
