9UPA | pdb_00009upa

Improved thermostability of a GH10 xylanase based on its X-ray crystal structure

PDB DOI: https://doi.org/10.2210/pdb9UPA/pdb

Classification: CARBOHYDRATE
Organism(s): Massilia sp. RBM26
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2025-04-28 Released: 2025-06-11
Deposition Author(s): Dong, P.P., Lu, P.
Funding Organization(s): National Natural Science Foundation of China (NSFC), Other government

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free:
0.295 (Depositor), 0.294 (DCC)
R-Value Work:
0.242 (Depositor), 0.241 (DCC)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9UPA

This is version 1.0 of the entry. See complete history.

Literature

Improved thermostability of a GH10 xylanase based on its X-ray crystal structure

Dong, P.P., Lu, P.

To be published.

Macromolecule Content

Total Structure Weight: 78.98 kDa
Atom Count: 5,629
Modeled Residue Count: 706
Deposited Residue Count: 706
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Beta-xylanase	A, B	353	Massilia sp. RBM26	Mutation(s): 0 EC: 3.2.1.8
UniProt
Find proteins for A0A0S2I9J6 (Massilia sp. RBM26) Explore A0A0S2I9J6 Go to UniProtKB: A0A0S2I9J6
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0S2I9J6
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.60 Å
R-Value Free: 0.295 (Depositor), 0.294 (DCC)
R-Value Work: 0.242 (Depositor), 0.241 (DCC)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 53.35	α = 90
b = 69.3	β = 91.914
c = 91.08	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
XDS	data reduction
XDS	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-06-11

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--
Other government	China	Zhejiang Provincial Natural Science Foundation of China LQN25C050002

Revision History (Full details and data files)

Version 1.0: 2025-06-11
Type: Initial release
