9T5W | pdb_00009t5w

Cryo-EM structure of mutant R61H alphaM/beta2 headpiece complex

PDB DOI: https://doi.org/10.2210/pdb9T5W/pdb
EM Map EMD-55597: EMDB EMDataResource

Classification: IMMUNE SYSTEM
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): Yes

Deposited: 2025-11-06 Released: 2026-03-25
Deposition Author(s): Andersen, G.R., Fruergaard, M.U.
Funding Organization(s): Other private

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.74 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of mutant R61H alphaM/beta2 headpiece complex

Andersen, G.R., Fruergaard, M.U.

To be published.

Macromolecule Content

Total Structure Weight: 140.43 kDa
Atom Count: 9,647
Modeled Residue Count: 1,210
Deposited Residue Count: 1,232
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isoform 2 of Integrin alpha-M	A	763	Homo sapiens	Mutation(s): 1 Gene Names: ITGAM, CD11B, CR3A
UniProt & NIH Common Fund Data Resources
Find proteins for P11215 (Homo sapiens) Go to UniProtKB: P11215
PHAROS: P11215 GTEx: ENSG00000169896
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P11215-2
Glycosylation
Glycosylation Sites: 5	Glycosylation Focus chain A	Go to GlyGen: P11215-1
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrin beta-2	B	469	Homo sapiens	Mutation(s): 0 Gene Names: ITGB2, CD18, MFI7
UniProt & NIH Common Fund Data Resources
Find proteins for P05107 (Homo sapiens) Explore P05107 Go to UniProtKB: P05107
PHAROS: P05107 GTEx: ENSG00000160255
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P05107
Glycosylation
Glycosylation Sites: 3	Glycosylation Focus chain B	Go to GlyGen: P05107-1
Sequence Annotations Expand
Reference Sequence

Oligosaccharides

Help

Entity ID: 3
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	C	3		N-Glycosylation	Interactions Focus chain C Interactions & Density Focus chain C

Entity ID: 4
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
alpha-D-mannopyranose-(1-3)-[alpha-D-mannopyranose-(1-6)]beta-D-mannopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	D, E	5		N-Glycosylation	Interactions Focus chain D Focus chain E Interactions & Density Focus chain D Focus chain E

Entity ID: 5
Molecule	Chains	Length	2D Diagram	Glycosylation	3D Interactions
2-acetamido-2-deoxy-beta-D-glucopyranose-(1-4)-2-acetamido-2-deoxy-beta-D-glucopyranose	F, G	2		N-Glycosylation	Interactions Focus chain F Focus chain G Interactions & Density Focus chain F Focus chain G

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAG Query on NAG Download Ideal Coordinates CCD File SDF format, chain K [auth A] SDF format, chain L [auth A] SDF format, chain P [auth B] MOL2 format, chain K [auth A] MOL2 format, chain L [auth A] MOL2 format, chain P [auth B] mmCIF format, chain K [auth A] mmCIF format, chain L [auth A] mmCIF format, chain P [auth B]	K [auth A], L [auth A], P [auth B]	2-acetamido-2-deoxy-beta-D-glucopyranose C₈ H₁₅ N O₆ OVRNDRQMDRJTHS-FMDGEEDCSA-N		Interactions Focus chain K [auth A] Focus chain L [auth A] Focus chain P [auth B] Interactions & Density Focus chain K [auth A] Focus chain L [auth A] Focus chain P [auth B]
MN Query on MN Download Ideal Coordinates CCD File SDF format, chain M [auth B] MOL2 format, chain M [auth B] mmCIF format, chain M [auth B]	M [auth B]	MANGANESE (II) ION Mn WAEMQWOKJMHJLA-UHFFFAOYSA-N		Interactions Focus chain M [auth B] Interactions & Density Focus chain M [auth B]
CA Query on CA Download Ideal Coordinates CCD File SDF format, chain H [auth A] SDF format, chain I [auth A] SDF format, chain J [auth A] SDF format, chain N [auth B] SDF format, chain O [auth B] MOL2 format, chain H [auth A] MOL2 format, chain I [auth A] MOL2 format, chain J [auth A] MOL2 format, chain N [auth B] MOL2 format, chain O [auth B] mmCIF format, chain H [auth A] mmCIF format, chain I [auth A] mmCIF format, chain J [auth A] mmCIF format, chain N [auth B] mmCIF format, chain O [auth B]	H [auth A], I [auth A], J [auth A], N [auth B], O [auth B]	CALCIUM ION Ca BHPQYMZQTOCNFJ-UHFFFAOYSA-N		Interactions Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B] Interactions & Density Focus chain H [auth A] Focus chain I [auth A] Focus chain J [auth A] Focus chain N [auth B] Focus chain O [auth B]
