9RT4 | pdb_00009rt4

NetF - ANTXR2 local refinement focused

PDB DOI: https://doi.org/10.2210/pdb9RT4/pdb
EM Map EMD-54245: EMDB EMDataResource

Classification: TOXIN
Organism(s): Homo sapiens, Clostridium perfringens
Expression System: Homo sapiens, Escherichia coli
Mutation(s): No

Deposited: 2025-07-02 Released: 2026-02-18
Deposition Author(s): Wang, C., Iacovache, I., Zuber, B.
Funding Organization(s): Swiss National Science Foundation

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: other
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9RT4

This is version 1.0 of the entry. See complete history.

Literature

Anthrax toxin receptor 2 is the Receptor for Clostridium perfringens NetF: Structural Insights into Toxin Binding and Pore Formation

Wang, C., Cattalani, F., Iacovache, I., Arunasalam, N., Posthaus, H., Zuber, B.

To be published.

Macromolecule Content

Total Structure Weight: 71.64 kDa
Atom Count: 3,016
Modeled Residue Count: 387
Deposited Residue Count: 645
Unique protein chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Anthrax toxin receptor 2	A [auth C1]	356	Homo sapiens	Mutation(s): 0 Gene Names: ANTXR2, CMG2
UniProt & NIH Common Fund Data Resources
Find proteins for P58335 (Homo sapiens) Explore P58335 Go to UniProtKB: P58335
PHAROS: P58335 GTEx: ENSG00000163297
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P58335
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Leukocidin/Hemolysin toxin family	B [auth N2]	289	Clostridium perfringens	Mutation(s): 0 Gene Names: netF, JFP838_pC0069
UniProt
Find proteins for A0A0D3QGV4 (Clostridium perfringens) Explore A0A0D3QGV4 Go to UniProtKB: A0A0D3QGV4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A0D3QGV4
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.60 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.21.2_5419
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-02-18

Deposition Author(s):

Funding Organization	Location	Grant Number
Swiss National Science Foundation	Switzerland	10000175

Revision History (Full details and data files)

Version 1.0: 2026-02-18
Type: Initial release
