9R70 | pdb_00009r70

Pyrin B30.2 domain, FMF mutation M680L

PDB DOI: https://doi.org/10.2210/pdb9R70/pdb

Classification: SIGNALING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2025-05-13 Released: 2025-06-18
Deposition Author(s): Mittl, P., Possner, D.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free:
0.212 (Depositor), 0.211 (DCC)
R-Value Work:
0.178 (Depositor), 0.178 (DCC)
R-Value Observed:
0.179 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9R70

This is version 1.0 of the entry. See complete history.

Literature

Pyrin B30.2 domain, FMF mutation M680L

Mittl, P., Possner, D.

To be published.

Macromolecule Content

Total Structure Weight: 21.7 kDa
Atom Count: 1,798
Modeled Residue Count: 195
Deposited Residue Count: 195
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Pyrin	A	195	Homo sapiens	Mutation(s): 1 Gene Names: MEFV, MEF, TRIM20
UniProt & NIH Common Fund Data Resources
Find proteins for O15553 (Homo sapiens) Explore O15553 Go to UniProtKB: O15553
PHAROS: O15553 GTEx: ENSG00000103313
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O15553
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain C [auth A] MOL2 format, chain C [auth A] mmCIF format, chain C [auth A]	C [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Interactions & Density Focus chain C [auth A]
SCN Query on SCN Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	THIOCYANATE ION C N S ZMZDMBWJUHKJPS-UHFFFAOYSA-M		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.50 Å
R-Value Free: 0.212 (Depositor), 0.211 (DCC)
R-Value Work: 0.178 (Depositor), 0.178 (DCC)
R-Value Observed: 0.179 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 42.364	α = 90
b = 60.231	β = 90
c = 84.051	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
Aimless	data scaling
XDS	data reduction
PDB_EXTRACT	data extraction
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-06-18

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2025-06-18
Type: Initial release
