9R2R | pdb_00009r2r

De novo designed M7 protein fold

• PDB DOI: https://doi.org/10.2210/pdb9R2R/pdb

• Classification: DE NOVO PROTEIN
• Organism(s): synthetic construct
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2025-04-30 Released: 2025-05-14
• Deposition Author(s): Pacesa, M., Miao, Y., Georgeon, S., Schmidt, J., Correia, B.E.
• Funding Organization(s): Swiss National Science Foundation

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.91 Å
• R-Value Free:
  0.302 (Depositor), 0.303 (DCC)
• R-Value Work:
  0.248 (Depositor), 0.248 (DCC)
• R-Value Observed:
  0.251 (Depositor)

Starting Model: in silico

Literature

Leveraging protein representations to explore uncharted fold spaces with generative models

Miao, Y., Pacesa, M., Georgeon, S., Schmidt, J., Lu, T., Huang, P.S., Correia, B.

(2025) bioRxiv

• DOI: https://doi.org/10.1101/2025.10.10.681606

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: gel filtration

Biological Assembly 2

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 2 assigned by authors.

Biological Assembly 3

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 3 assigned by authors.

Biological Assembly 4

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 4 assigned by authors.

Macromolecule Content

• Total Structure Weight: 69.14 kDa
• Atom Count: 4,457
• Modeled Residue Count: 524
• Deposited Residue Count: 576
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
M7r1	A, B [auth C], C [auth D], D [auth B]	144	synthetic construct	Mutation(s): 0

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.91 Å
• R-Value Free:  0.302 (Depositor), 0.303 (DCC)
• R-Value Work:  0.248 (Depositor), 0.248 (DCC)
• R-Value Observed: 0.251 (Depositor)

Space Group: C 1 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 101.48	α = 90
b = 88.58	β = 114.038
c = 65.75	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
autoPROC	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

Entry History

& Funding Information

Deposition Data

• Released Date: 2025-05-14
Deposition Author(s): Pacesa, M., Miao, Y., Georgeon, S., Schmidt, J., Correia, B.E.

---

Funding Organization	Location	Grant Number
Swiss National Science Foundation		--

Revision History

• Version 1.0: 2025-05-14
  Type: Initial release

• Version 1.1: 2025-11-26
  Changes: Database references
