9QBV | pdb_00009qbv

Crystal structure of WRN in complex with (R)-11 (GSK4766470)

PDB DOI: https://doi.org/10.2210/pdb9QBV/pdb

Classification: TRANSFERASE
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2025-03-03 Released: 2026-03-11
Deposition Author(s): Chaikuad, A., Concha, N., Chung, C.-W.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.15 Å
R-Value Free:
0.258 (Depositor), 0.263 (DCC)
R-Value Work:
0.193 (Depositor), 0.203 (DCC)
R-Value Observed:
0.196 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of WRN in complex with (R)-11 (GSK4766470)

Chaikuad, A., Concha, N., Chung, C.-W.

To be published.

Macromolecule Content

Total Structure Weight: 51.26 kDa
Atom Count: 3,482
Modeled Residue Count: 418
Deposited Residue Count: 443
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bifunctional 3'-5' exonuclease/ATP-dependent helicase WRN	A	443	Homo sapiens	Mutation(s): 0 Gene Names: WRN, RECQ3, RECQL2 EC: 3.1 (PDB Primary Data), 5.6.2.4 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q14191 (Homo sapiens) Explore Q14191 Go to UniProtKB: Q14191
PHAROS: Q14191 GTEx: ENSG00000165392
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q14191
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1I5F (Subject of Investigation/LOI) Query on A1I5F Download Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	1-[(2~{R})-2-methyl-4-[2-[4-(trifluoromethyl)phenyl]ethanoyl]piperazin-1-yl]propan-1-one C₁₇ H₂₁ F₃ N₂ O₂ BIKYEXUTFXMVAZ-GFCCVEGCSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain I [auth A] MOL2 format, chain I [auth A] mmCIF format, chain I [auth A]	I [auth A]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain I [auth A] Interactions & Density Focus chain I [auth A]
EDO Query on EDO Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth A] SDF format, chain E [auth A] SDF format, chain F [auth A] SDF format, chain G [auth A] SDF format, chain H [auth A] MOL2 format, chain C [auth A] MOL2 format, chain D [auth A] MOL2 format, chain E [auth A] MOL2 format, chain F [auth A] MOL2 format, chain G [auth A] MOL2 format, chain H [auth A] mmCIF format, chain C [auth A] mmCIF format, chain D [auth A] mmCIF format, chain E [auth A] mmCIF format, chain F [auth A] mmCIF format, chain G [auth A] mmCIF format, chain H [auth A]	C [auth A] D [auth A] E [auth A] F [auth A] G [auth A] C [auth A], D [auth A], E [auth A], F [auth A], G [auth A], H [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain E [auth A] Focus chain F [auth A] Focus chain G [auth A] Focus chain H [auth A]
