9Q3A | pdb_00009q3a

Structure of the Borna Disease Virus 1 L and co-factor P Protein in an apo state


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.77 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Structure and function of the RNA polymerase complex of Borna disease virus, a nuclear-replicating non-segmented negative-strand RNA virus.

Gibbs, E.Ogino, M.Kanda, T.Watkins, D.Whiddon, K.Tomonaga, K.Chakrapani, S.Ogino, T.

(2026) Nucleic Acids Res 54

  • DOI: https://doi.org/10.1093/nar/gkaf1413
  • Primary Citation of Related Structures:
    9Q3A

  • PubMed Abstract:

    Borna disease virus 1 (BoDV-1) is a non-segmented negative-strand (NNS) RNA virus that uniquely replicates in the nucleus of mammalian host cells, in contrast to most NNS RNA viruses that replicate in the cytoplasm. The mechanisms underlying nuclear replication of BoDV-1 and related bornaviruses with their RNA-dependent RNA polymerase (RdRp) complexes remain poorly understood. Here, we report the 2.8 Å cryo-EM structure of the BoDV-1 RdRp complex, comprising the large (L) protein and tetrameric phosphoprotein (P). The L protein features an N-terminal superdomain containing the RdRp and GDP polyribonucleotidyltransferase (PRNTase, mRNA-capping enzyme) domains, along with three C-terminal appendages, including a methyltransferase-like domain. The RdRp initiates de novo RNA synthesis internally at the genomic promoter, producing 5'-triphosphorylated transcripts corresponding to the 5' end of the anti-genome. P interacts with the fingers RdRp subdomain of L. Structure-guided mutagenesis shows that the residues involved in the L-P interaction are essential for efficient transcription initiation and, consequently, for viral gene expression. A flexible loop within the PRNTase domain, analogous to the rhabdovirus priming-capping loop, appears critical for transcription initiation. These findings provide the structural and functional insights into the BoDV-1 RdRp and support a shared evolutionary origin between nuclear and cytoplasmic NNS RNA viruses.


  • Organizational Affiliation
    • Department of Pharmacology, School of Medicine, Case Western Reserve University, Cleveland, OH 44106, United States.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
RNA-directed RNA polymerase L1,721Borna disease virus 1Mutation(s): 0
EC: 2.7.7.48
UniProt
Find proteins for Q8JMN0 (Borna disease virus 1)
Explore Q8JMN0
Go to UniProtKB:  Q8JMN0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8JMN0
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
Isoform p24 of PhosphoproteinB [auth D],
C [auth B],
D [auth C],
E
201Borna disease virus 1Mutation(s): 0
Gene Names: P/X
UniProt
Find proteins for P0C798 (Borna disease virus 1)
Explore P0C798
Go to UniProtKB:  P0C798
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP0C798
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ZN
Query on ZN

Download Ideal Coordinates CCD File
F [auth A]ZINC ION
Zn
PTFCDOFLOPIGGS-UHFFFAOYSA-N
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.77 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONRELION5.0
MODEL REFINEMENTPHENIX1.21.2-5419

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR21 AI176323
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United StatesR01 AI146172

Revision History  (Full details and data files)

  • Version 1.0: 2026-01-21
    Type: Initial release
