9PSY | pdb_00009psy

Q108K:K40L:T51V:T53S:R58W:Y19W:L117E mutant of hCRBPII bound to fluorophore TD-1V-1

PDB DOI: https://doi.org/10.2210/pdb9PSY/pdb

Classification: RETINOL BINDING PROTEIN
Organism(s): Homo sapiens
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2025-07-27 Released: 2025-10-01
Deposition Author(s): Ghanbarpour, A., Bingham, C., Geiger, J.H.
Funding Organization(s): National Institutes of Health/National Institute of Biomedical Imaging and Bioengineering (NIH/NIBIB)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.62 Å
R-Value Free:
0.245 (Depositor), 0.245 (DCC)
R-Value Work:
0.221 (Depositor), 0.220 (DCC)
R-Value Observed:
0.222 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9PSY

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Exploring the Structure-Property Relationships of Protein/Fluorophore Complex

Santos, E., Ghanbarpour, A., Chandra, I., Bingham, C., Vasileiou, C., Geiger, J.H., Borhan, B.

To be published.

Macromolecule Content

Total Structure Weight: 31.9 kDa
Atom Count: 2,383
Modeled Residue Count: 266
Deposited Residue Count: 266
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Retinol-binding protein 2	A, B	133	Homo sapiens	Mutation(s): 7 Gene Names: RBP2, CRBP2
UniProt & NIH Common Fund Data Resources
Find proteins for P50120 (Homo sapiens) Explore P50120 Go to UniProtKB: P50120
PHAROS: P50120 GTEx: ENSG00000114113
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P50120
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1CKX (Subject of Investigation/LOI) Query on A1CKX Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain E [auth B] MOL2 format, chain C [auth A] MOL2 format, chain E [auth B] mmCIF format, chain C [auth A] mmCIF format, chain E [auth B]	C [auth A], E [auth B]	(2E)-3-(5-phenylthiophen-2-yl)but-2-enal C₁₄ H₁₂ O S KANGHGOOGHOANR-PKNBQFBNSA-N		Interactions Focus chain C [auth A] Focus chain E [auth B] Interactions & Density Focus chain C [auth A] Focus chain E [auth B]
ACT Query on ACT Download:Ideal Coordinates CCD File SDF format, chain D [auth A] SDF format, chain G [auth B] SDF format, chain F [auth B] MOL2 format, chain D [auth A] MOL2 format, chain G [auth B] MOL2 format, chain F [auth B] mmCIF format, chain D [auth A] mmCIF format, chain G [auth B] mmCIF format, chain F [auth B]	D [auth A], F [auth B], G [auth B]	ACETATE ION C₂ H₃ O₂ QTBSBXVTEAMEQO-UHFFFAOYSA-M		Interactions Focus chain D [auth A] Focus chain F [auth B] Focus chain G [auth B] Interactions & Density Focus chain D [auth A] Focus chain F [auth B] Focus chain G [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.62 Å
R-Value Free: 0.245 (Depositor), 0.245 (DCC)
R-Value Work: 0.221 (Depositor), 0.220 (DCC)
R-Value Observed: 0.222 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 29.297	α = 90
b = 66.84	β = 90.752
c = 64.068	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
Coot	model building
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-10-01

Deposition Author(s):

Ghanbarpour, A.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of Biomedical Imaging and Bioengineering (NIH/NIBIB)	United States	--

Revision History (Full details and data files)

Version 1.0: 2025-10-01
Type: Initial release
