9PJC | pdb_00009pjc

Rox_LL cross alpha peptide filament

PDB DOI: https://doi.org/10.2210/pdb9PJC/pdb
EM Map EMD-71686: EMDB EMDataResource

Classification: PROTEIN FIBRIL
Organism(s): synthetic construct
Mutation(s): No

Deposited: 2025-07-13 Released: 2026-07-29
Deposition Author(s): Das, A., Conticello, V.P., Wang, F., Egelman, E.H.
Funding Organization(s): National Science Foundation (NSF, United States)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.80 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

wwPDB Validation 3D Report Full Report

Validation slider image for 9PJC

This is version 1.0 of the entry. See complete history.

Literature

Rox_LL cross alpha peptide filament

Das, A., Conticello, V.P., Wang, F., Egelman, E.H., Paravastu, A.K., Dinakarapandian, D.K., Zuo, X., Wang, S.

To be published.

Macromolecule Content

Total Structure Weight: 117.09 kDa
Atom Count: 8,300
Modeled Residue Count: 1,150
Deposited Residue Count: 1,150
Unique protein chains: 1

Macromolecules

Find similar proteins by: Sequence | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ACE-GLU-ALA-LEU-GLN-LEU-ALA-LYS-GLU-ALA-LEU-TYR-LEU-ALA-GLU-LYS-ALA-LEU-GLN-LEU-ALA-LYS	A [auth D] AA [auth d] B [auth C] BA [auth c] C [auth F] A [auth D], AA [auth d], B [auth C], BA [auth c], C [auth F], CA [auth f], D [auth E], DA [auth e], E [auth H], EA [auth h], F [auth G], FA [auth g], G [auth J], GA [auth j], H [auth I], HA [auth i], I [auth L], IA [auth l], J [auth K], JA [auth k], K [auth N], KA [auth n], L [auth M], LA [auth m], M [auth P], MA [auth p], N [auth O], NA [auth o], O [auth R], OA [auth r], P [auth Q], PA [auth q], Q [auth T], QA [auth t], R [auth S], RA [auth s], S [auth V], SA [auth v], T [auth U], TA [auth u], U [auth X], UA [auth x], V [auth W], VA [auth w], W [auth Z], WA [auth B], X [auth Y], XA [auth A], Y [auth b], Z [auth a]	23	synthetic construct	Mutation(s): 0
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.80 Å
Aggregation State: FILAMENT
Reconstruction Method: HELICAL

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC
MODEL REFINEMENT	PHENIX

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-29

Deposition Author(s):

Conticello, V.P.

Funding Organization	Location	Grant Number
National Science Foundation (NSF, United States)	United States	--

Revision History (Full details and data files)

Version 1.0: 2026-07-29
Type: Initial release
