9OEF | pdb_00009oef

Structure of the human astrovirus VA1 capsid spike bound to antibody 7C8

PDB DOI: https://doi.org/10.2210/pdb9OEF/pdb
EM Map EMD-70397: EMDB EMDataResource

Classification: VIRAL PROTEIN
Organism(s): Astrovirus VA1, Mus musculus
Expression System: Escherichia coli, Cricetulus griseus
Mutation(s): No

Deposited: 2025-04-28 Released: 2026-07-08
Deposition Author(s): Ghosh, A., Dzimianski, J.V., Balasco Serrao, V.H., DuBois, R.M.
Funding Organization(s): National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.69 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental, in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9OEF

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM Structures of the Human Astrovirus VA1 Capsid Spike Bound to Neutralizing Antibodies: Implications for Therapeutic Strategies

Ghosh, A., Dzimianski, J.V., Lopez, T., Espinosa, R., Balasco Serrao, V.H., Arias, C.F., DuBois, R.M.

To be published.

Macromolecule Content

Total Structure Weight: 158.3 kDa
Atom Count: 7,148
Modeled Residue Count: 908
Deposited Residue Count: 1,446
Unique protein chains: 3

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Spike protein VP38	A [auth C], D [auth A]	289	Astrovirus VA1	Mutation(s): 0 Gene Names: ORF2
UniProt
Find proteins for C7BG48 (Human astrovirus VA1) Explore C7BG48 Go to UniProtKB: C7BG48
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	C7BG48
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
7C8 heavy chain	B [auth H], E [auth J]	219	Mus musculus	Mutation(s): 0

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
7C8 light chain	C [auth L], F [auth K]	215	Mus musculus	Mutation(s): 0

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.69 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4.5.3
MODEL REFINEMENT	ISOLDE
MODEL REFINEMENT	PHENIX	1.21.2-5419

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-07-08

Deposition Author(s):

Dzimianski, J.V.

Balasco Serrao, V.H.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)	United States	R01AI144090

Revision History (Full details and data files)

Version 1.0: 2026-07-08
Type: Initial release
