9NXM | pdb_00009nxm

Crystal structure of Arabidopsis thaliana NUDT11 E90Q/E94Q mutant

PDB DOI: https://doi.org/10.2210/pdb9NXM/pdb

Classification: PLANT PROTEIN
Organism(s): Arabidopsis thaliana
Expression System: Escherichia coli BL21(DE3)
Mutation(s): Yes

Deposited: 2025-03-25 Released: 2026-04-01
Deposition Author(s): Chu, H.F., Liang, T.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.41 Å
R-Value Free:
0.249 (Depositor), 0.247 (DCC)
R-Value Work:
0.211 (Depositor), 0.211 (DCC)
R-Value Observed:
0.215 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9NXM

This is version 1.0 of the entry. See complete history.

Literature

Arabidopsis thaliana NUDT11 E90/94Q mutant

Chu, H.F., Liang, T.

To be published.

Macromolecule Content

Total Structure Weight: 25.98 kDa
Atom Count: 1,745
Modeled Residue Count: 213
Deposited Residue Count: 224
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nudix hydrolase 11	A	224	Arabidopsis thaliana	Mutation(s): 2 Gene Names: NUDT11, NUDX11, At5g45940, K15I22.14 EC: 3.6.1
UniProt
Find proteins for Q8LET2 (Arabidopsis thaliana) Explore Q8LET2 Go to UniProtKB: Q8LET2
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q8LET2
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
EDO Query on EDO Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	1,2-ETHANEDIOL C₂ H₆ O₂ LYCAIKOWRPUZTN-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.41 Å
R-Value Free: 0.249 (Depositor), 0.247 (DCC)
R-Value Work: 0.211 (Depositor), 0.211 (DCC)
R-Value Observed: 0.215 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 82.572	α = 90
b = 82.572	β = 90
c = 86.847	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XDS	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-04-01

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R35GM118093

Revision History (Full details and data files)

Version 1.0: 2026-04-01
Type: Initial release
