9NX5 | pdb_00009nx5

Crystal Structure of a P. Aeruginosa Gyrase


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:
    0.257 (Depositor), 0.257 (DCC)
  • R-Value Work:
    0.242 (Depositor), 0.242 (DCC)
  • R-Value Observed:
    0.243 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9NX5

This is version 1.0 of the entry. See complete history

Literature

Structural and Computational Analysis of Pseudomonas aeruginosa DNA Gyrase Reveals Molecular Characteristics That May Contribute to Ciprofloxacin Resistance.

Perera, L.Garcia-Villada, L.Kaminski, A.M.Degtyareva, N.Pedersen, L.C.Doetsch, P.W.

(2025) bioRxiv

  • DOI: https://doi.org/10.64898/2025.12.19.695517
  • Primary Citation Related Structures:
    9NX5

  • PubMed Abstract:

    Pseudomonas aeruginosa is considered a priority pathogen by the World Health Organization due to its resistance to antibiotics. Isolates resistant to ciprofloxacin (CPFX), a bactericide commonly used against P. aeruginosa , usually carry the mutations T83I or D87N in the GyrA subunit of the DNA gyrase. Yet, the molecular mechanisms by which these mutations confer CPFX-resistance to P. aeruginosa are unknown. Here we solved the crystal structure of the P. aeruginosa gyrase catalytic cleavage core and used it to carry out molecular dynamic (MD) simulations of CPFX-gyrase binding in the wild-type as well as the T83I and the D87N mutant systems. Our results show that DNA plays the most prominent role in maintaining the CPFX-bound conformation, with no appreciable contributions from Thr83 or Asp87. Interestingly, we found a solvent cavity adjacent to these residues that may provide CPFX access to the active site. Interaction energy analysis using Umbrella Sampling indicates that Thr83 and Asp87 may influence CPFX trajectory during binding. In the mutant systems, the attractive potential decreases, which may hinder CPFX accessing the binding site. These results shed light on P. aeruginosa resistance to CPFX and may help provide a methodology to identify new therapeutic agents to target fluoroquinolone resistant bacteria.


  • Organizational Affiliation
    • Genomic Integrity & Structural Biology Laboratory, NIEHS, Durham, 27709, NC, USA.

Macromolecule Content

  • Total Structure Weight: 105.85 kDa
  • Atom Count: 6,746
  • Modeled Residue Count: 866
  • Deposited Residue Count: 942
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
DNA gyrase subunit B,DNA gyrase subunit A942Pseudomonas aeruginosaMutation(s): 0
Gene Names: gyrBgyrACSB93_3133
EC: 5.6.2.2
UniProt
Find proteins for A0A2R3INH2 (Pseudomonas paraeruginosa)
Explore A0A2R3INH2
Go to UniProtKB:  A0A2R3INH2
Find proteins for Q9S1C7 (Pseudomonas aeruginosa)
Explore Q9S1C7
Go to UniProtKB:  Q9S1C7
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupsA0A2R3INH2Q9S1C7
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.40 Å
  • R-Value Free:  0.257 (Depositor), 0.257 (DCC)
  • R-Value Work:  0.242 (Depositor), 0.242 (DCC)
  • R-Value Observed: 0.243 (Depositor)
Space Group: P 63 2 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 218.159α = 90
b = 218.159β = 90
c = 108.803γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
PHASERphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesZICES102645
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesZICES043010
National Institutes of Health/National Institute of Environmental Health Sciences (NIH/NIEHS)United StatesZ1AES103328

Revision History  (Full details and data files)

  • Version 1.0: 2026-04-22
    Type: Initial release
