9NWS | pdb_00009nws

Cryo-EM structure of DDB1dB:CRBN:mezigdomide:SALL4(392-449)


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

Starting Models: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.0 of the entry. See complete history


Literature

Expanding the druggable zinc-finger proteome defines properties of drug-induced degradation.

Slabicki, M.Park, J.Nowak, R.P.Roy Burman, S.S.Pellman, J.Zou, C.Razumkov, H.Carreiro, J.Rastogi, S.Goldstein, A.Nagiec, M.M.Donovan, K.A.Che, J.Hunkeler, M.Geng, Q.Hsu, C.L.Lakshminarayan, M.Shu, C.Zon, R.L.Kozicka, Z.Park, P.M.C.Tsai, J.M.Yoon, H.Jones, L.H.Sperling, A.S.Gray, N.S.Fischer, E.S.Ebert, B.L.

(2025) Mol Cell 85: 3184-3201.e14

  • DOI: https://doi.org/10.1016/j.molcel.2025.07.019
  • Primary Citation of Related Structures:
    9E2U, 9NWS, 9NWT

  • PubMed Abstract:

    Glutarimide analogs, such as thalidomide, redirect the E3 ubiquitin ligase CRL4 CRBN to induce degradation of certain zinc finger (ZF) proteins. Although the core structural motif recognized by CRBN has been characterized, it does not fully explain substrate specificity. To explore the role of residues adjacent to this core motif, we constructed a comprehensive ZF reporter library of 9,097 reporters derived from 1,655 human ZF proteins and conducted a library-on-library screen with 29 glutarimide analogs to identify compounds that collectively degrade 38 ZF reporters. Cryo-electron microscopy and crystal structures of ZFs in complex with CRBN revealed the importance of interactions beyond the core ZF degron. We used systematic mutagenesis of ZFs and CRBN to identify modes of neosubstrate recruitment requiring distinct amino acids. Finally, we found subtle chemical variations in glutarimide analogs that alter target scope and selectivity, thus providing a roadmap for their rational design.


  • Organizational Affiliation
    • Department of Medical Oncology, Dana-Farber Cancer Institute, Boston, MA 02115, USA; Broad Institute of MIT and Harvard, Cambridge, MA 02142, USA; Krantz Family Center for Cancer Research, Massachusetts General Hospital Cancer Center, Charlestown, MA 02129, USA. Electronic address: mslabicki@mgh.harvard.edu.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Sal-like protein 4A [auth C]102Homo sapiensMutation(s): 0
Gene Names: SALL4ZNF797
UniProt & NIH Common Fund Data Resources
Find proteins for Q9UJQ4 (Homo sapiens)
Explore Q9UJQ4
Go to UniProtKB:  Q9UJQ4
PHAROS:  Q9UJQ4
GTEx:  ENSG00000101115
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UJQ4
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 2
MoleculeChains Sequence LengthOrganismDetailsImage
DNA damage-binding protein 1B [auth A]860Homo sapiensMutation(s): 0
Gene Names: DDB1XAP1
UniProt & NIH Common Fund Data Resources
Find proteins for Q16531 (Homo sapiens)
Explore Q16531
Go to UniProtKB:  Q16531
PHAROS:  Q16531
GTEx:  ENSG00000167986
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ16531
Sequence Annotations
Expand
  • Reference Sequence
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 3
MoleculeChains Sequence LengthOrganismDetailsImage
Protein cereblonC [auth B]485Homo sapiensMutation(s): 0
Gene Names: CRBN
UniProt & NIH Common Fund Data Resources
Find proteins for Q96SW2 (Homo sapiens)
Explore Q96SW2
Go to UniProtKB:  Q96SW2
PHAROS:  Q96SW2
GTEx:  ENSG00000113851
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ96SW2
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 2.70 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
RECONSTRUCTIONcryoSPARC4.2.0
MODEL REFINEMENTPHENIX1.21-5207

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)United StatesR01CA214608

Revision History  (Full details and data files)

  • Version 1.0: 2026-02-04
    Type: Initial release
