9NEJ | pdb_00009nej

AZD-3 bound EFPA transporter of Mycobacterium tuberculosis

PDB DOI: https://doi.org/10.2210/pdb9NEJ/pdb
EM Map EMD-49313: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Mycobacterium tuberculosis H37Rv
Expression System: Escherichia coli BL21
Mutation(s): Yes

Deposited: 2025-02-19 Released: 2026-03-04
Deposition Author(s): Khandelwal, N.K., Gupta, M., Stroud, R.M.
Funding Organization(s): National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.10 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9NEJ

This is version 1.0 of the entry. See complete history.

Literature

AZD-3 bound EFPA transporter of Mycobacterium tuberculosis

Khandelwal, N.K., Gupta, M., Stroud, R.M.

To be published.

Macromolecule Content

Total Structure Weight: 138.35 kDa
Atom Count: 7,208
Modeled Residue Count: 940
Deposited Residue Count: 1,258
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uncharacterized MFS-type transporter EfpA	A, B	629	Mycobacterium tuberculosis H37Rv	Mutation(s): 1 Gene Names: efpA, Rv2846c
UniProt
Find proteins for P9WJY5 (Mycobacterium tuberculosis (strain ATCC 25618 / H37Rv)) Explore P9WJY5 Go to UniProtKB: P9WJY5
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P9WJY5
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1BXT Query on A1BXT Download:Ideal Coordinates CCD File SDF format, chain D [auth A] MOL2 format, chain D [auth A] mmCIF format, chain D [auth A]	D [auth A]	(2R)-3-{[(S)-[(2R)-2,3-dihydroxypropoxy](hydroxy)phosphoryl]oxy}-2-{[(10E)-hexadec-10-enoyl]oxy}propyl (9E,14E)-octadeca-9,14-dienoate C₄₀ H₇₃ O₁₀ P UAKNDDGOSJFMJQ-JMBLMXHZSA-N		Interactions Focus chain D [auth A] Interactions & Density Focus chain D [auth A]
A1ATG (Subject of Investigation/LOI) Query on A1ATG Download:Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain F [auth B] SDF format, chain H [auth B] SDF format, chain I [auth B] SDF format, chain J [auth B] MOL2 format, chain C [auth A] MOL2 format, chain F [auth B] MOL2 format, chain H [auth B] MOL2 format, chain I [auth B] MOL2 format, chain J [auth B] mmCIF format, chain C [auth A] mmCIF format, chain F [auth B] mmCIF format, chain H [auth B] mmCIF format, chain I [auth B] mmCIF format, chain J [auth B]	C [auth A], F [auth B], H [auth B], I [auth B], J [auth B]	(2S)-3-{[(R)-[(2R)-2,3-dihydroxypropoxy](hydroxy)phosphoryl]oxy}-2-{[(2E,9E,13E)-hexadeca-2,9,13-trienoyl]oxy}propyl (4E,9E,11Z,15E)-octadeca-4,9,11,15-tetraenoate C₄₀ H₆₅ O₁₀ P QWNODTQZPQWNIK-WKOXGUCKSA-N		Interactions Focus chain C [auth A] Focus chain F [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B] Interactions & Density Focus chain C [auth A] Focus chain F [auth B] Focus chain H [auth B] Focus chain I [auth B] Focus chain J [auth B]
A1BXW (Subject of Investigation/LOI) Query on A1BXW Download:Ideal Coordinates CCD File SDF format, chain E [auth A] SDF format, chain G [auth B] MOL2 format, chain E [auth A] MOL2 format, chain G [auth B] mmCIF format, chain E [auth A] mmCIF format, chain G [auth B]	E [auth A], G [auth B]	(2P)-2-(2-methoxyphenyl)-N-(3-methoxyphenyl)-1-methyl-1H-pyrrolo[3,2-c]pyridin-4-amine C₂₂ H₂₁ N₃ O₂ UQASDSGYXMMHAO-UHFFFAOYSA-N		Interactions Focus chain E [auth A] Focus chain G [auth B] Interactions & Density Focus chain E [auth A] Focus chain G [auth B]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.10 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	v4.2.1
MODEL REFINEMENT	PHENIX	1.21_5207-000

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-03-04

Deposition Author(s):

Khandelwal, N.K.

Funding Organization	Location	Grant Number
National Institutes of Health/National Institute of General Medical Sciences (NIH/NIGMS)	United States	R01GM024485

Revision History (Full details and data files)

Version 1.0: 2026-03-04
Type: Initial release
