9ND5 | pdb_00009nd5

JAK2 pseudokinase domain in complex with diaminotriazole covalent inhibitor

PDB DOI: https://doi.org/10.2210/pdb9ND5/pdb

Classification: TRANSFERASE/TRANSFERASE INHIBITOR
Organism(s): Homo sapiens
Expression System: Spodoptera frugiperda
Mutation(s): No

Deposited: 2025-02-17 Released: 2025-11-05
Deposition Author(s): Primi, M.C., Eck, M.J.
Funding Organization(s): National Institutes of Health/National Cancer Institute (NIH/NCI)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free:
0.278 (Depositor), 0.280 (DCC)
R-Value Work:
0.211 (Depositor), 0.245 (DCC)
R-Value Observed:
0.214 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9ND5

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

JAK2 pseudokinase domain in complex with diaminotriazole covalent inhibitor

Primi, M.C., Eck, M.J.

To be published.

Macromolecule Content

Total Structure Weight: 32.89 kDa
Atom Count: 2,319
Modeled Residue Count: 274
Deposited Residue Count: 280
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Tyrosine-protein kinase JAK2	A	280	Homo sapiens	Mutation(s): 0 Gene Names: JAK2 EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for O60674 (Homo sapiens) Explore O60674 Go to UniProtKB: O60674
PHAROS: O60674 GTEx: ENSG00000096968
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O60674
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1BXA (Subject of Investigation/LOI) Query on A1BXA Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	4-{[5-amino-1-(3-{[fluorodi(hydroxy)-lambda~4~-sulfanyl]oxy}benzoyl)-1H-1,2,4-triazol-3-yl]amino}benzene-1-sulfonamide C₁₅ H₁₅ F N₆ O₆ S₂ VNMSMWQDKZDYKK-UHFFFAOYSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.40 Å
R-Value Free: 0.278 (Depositor), 0.280 (DCC)
R-Value Work: 0.211 (Depositor), 0.245 (DCC)
R-Value Observed: 0.214 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.165	α = 90
b = 61.037	β = 90
c = 86.154	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
Aimless	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-11-05

Deposition Author(s):

Funding Organization	Location	Grant Number
National Institutes of Health/National Cancer Institute (NIH/NCI)	United States	5R35CA242461-06

Revision History (Full details and data files)

Version 1.0: 2025-11-05
Type: Initial release
