CryoEM structure of WNV (Kunjin strain) with the Fab of WNV-86 antibody


Experimental Data Snapshot

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9N3B

This is version 1.1 of the entry. See complete history

Literature

A distinct E dimer epitope underlies selective recognition by a protective human West Nile virus antibody.

Khare, B.Arnaud, C.A.Klose, T.Crowe Jr., J.E.Kuhn, R.J.

(2026) EMBO Rep

  • DOI: https://doi.org/10.1038/s44319-026-00851-z
  • Primary Citation Related Structures:
    9N3B

  • PubMed Abstract:

    Human outbreaks of West Nile virus (WNV) are an imminent threat in North America, with many annual infections and numerous cases of severe neuroinvasive disease. There are no licensed treatments for WNV disease. Previous research identified WNV-86 as an ultrapotent neutralizing human antibody that binds domain II of the major envelope (E) glycoprotein in mature virions. Here, we report the structure of mature WNV in complex with the Fab of WNV-86, at a resolution of 3.8 Å, solved using cryogenic electron microscopy. Structure-based epitope mapping identifies a new class of E dimer epitope (EDE) antibodies that we designate as EDE3 antibodies. A partial overlap of WNV-86 and pre-membrane protein (prM) binding regions at more than one site ensures selective binding of WNV-86 to mature virions. The structure reveals the quaternary epitope of the neutralizing Fab and supports a model in which engaging both protomers of the dimer likely interferes with fusion-triggering rearrangements. This study identifies critical residues for binding, neutralization, and immune escape and clarifies the promise of this molecule for future immunotherapeutic interventions.


  • Organizational Affiliation
    • Department of Biological Sciences, Purdue University, West Lafayette, IN, USA.

Macromolecule Content

  • Total Structure Weight: 211.64 kDa
  • Atom Count: 14,852
  • Modeled Residue Count: 1,958
  • Deposited Residue Count: 1,958
  • Unique protein chains: 4

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Envelope protein E
A, C, E
500Kunjin virusMutation(s): 0
UniProt
Find proteins for P14335 (Kunjin virus (strain MRM61C))
Explore P14335
Go to UniProtKB:  P14335
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14335
Glycosylation
Glycosylation Sites: 1
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
Small envelope protein M
B, D, F
75Kunjin virusMutation(s): 0
UniProt
Find proteins for P14335 (Kunjin virus (strain MRM61C))
Explore P14335
Go to UniProtKB:  P14335
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP14335
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 3
MoleculeChains  Sequence LengthOrganismDetailsImage
WNV-86 heavy chainG [auth H]126Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 4
MoleculeChains  Sequence LengthOrganismDetailsImage
WNV-86 light chainH [auth L]107Homo sapiensMutation(s): 0
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: ELECTRON MICROSCOPY
  • Resolution: 3.80 Å
  • Aggregation State: PARTICLE
  • Reconstruction Method: SINGLE PARTICLE
EM Software:
TaskSoftware PackageVersion
MODEL REFINEMENTPHENIX1.21.1_5286:
RECONSTRUCTIONcryoSPARC4.5.3

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Institutes of Health/National Institute Of Allergy and Infectious Diseases (NIH/NIAID)United States--

Revision History  (Full details and data files)

  • Version 1.0: 2026-07-08
    Type: Initial release
  • Version 1.1: 2026-07-15
    Changes: Data collection, Database references
