9LXG | pdb_00009lxg

Filamin A repeat 21 in complex with LARP4 Ala269-Asn281 peptide


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.46 Å
  • R-Value Free:
    0.259 (Depositor), 0.218 (DCC)
  • R-Value Work:
    0.204 (Depositor), 0.205 (DCC)
  • R-Value Observed:
    0.207 (Depositor)

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9LXG

This is version 1.1 of the entry. See complete history

Literature

Structural Basis of the LARP4-Filamin A Interaction and Competition with Integrin beta 7 Tails.

Mao, Z.Ding, Y.Liu, Y.Mei, K.Nakamura, F.

(2025) J Mol Biology 437: 169262-169262

  • DOI: https://doi.org/10.1016/j.jmb.2025.169262
  • Primary Citation Related Structures:
    9LWX, 9LXG

  • PubMed Abstract:

    Filamin A (FLNA) is an actin cross-linking protein that connects multiple transmembrane receptors and cytosolic signaling proteins to regulate cell shape, motility, and signaling. Our previous report has shown that FLNA interacts directly with the La-related protein 4 (LARP4) and this interaction is essential for cell migration. Here, using the x-ray crystallography and protein-protein interaction studies, we investigated the molecular basis of LARP4 binding to FLNA. We described the high-resolution structure of the FLNA immunoglobulin-like repeat 21 (R21) and its complex with the LARP4 peptide. The FLNA-binding site in LARP4 is localized between Ala269 and Asn281, where it forms an extended β strand that interacts with the cleft formed by β strands C and D of FLNA R21. Consistent with this structure, the A279Cfs*2 mutation found in catalogue of somatic mutations in cancer (COSMIC) database and the experimentally introduced F277A mutation both disrupt LARP4 binding to FLNA. In contrast, the COSMIC-listed N275S mutation alters LARP4 membrane localization without affecting FLNA interaction, suggesting distinct functional outcomes. Cell migration assays showed that LARP4-knockdown cells expressing FLNA-binding-deficient mutants migrated faster than those expressing wild-type LARP4. The LARP4-binding site on FLNA overlaps with the β-integrin tail-binding region, and in vitro assays revealed that LARP4 can compete with integrin β7 tails for FLNA R21 binding. These results suggest that the LARP4-FLNA interaction may regulate cell migration, at least in part, by competing with integrin tails, although this mechanism has yet to be confirmed in vivo.


  • Organizational Affiliation
    • School of Pharmaceutical Science and Technology, Tianjin University, Tianjin 300072, China.

Macromolecule Content

  • Total Structure Weight: 11.68 kDa
  • Atom Count: 812
  • Modeled Residue Count: 109
  • Deposited Residue Count: 114
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Filamin-A101Esselenichthys carliMutation(s): 0
Gene Names: FLNAFLNFLN1
UniProt & NIH Common Fund Data Resources
Find proteins for P21333 (Homo sapiens)
Explore P21333
Go to UniProtKB:  P21333
PHAROS:  P21333
GTEx:  ENSG00000196924
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP21333
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:  Sequence   |   3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
La-related protein 413Esselenichthys carliMutation(s): 0
Gene Names: Larp4
UniProt
Find proteins for Q8BWW4 (Mus musculus)
Explore Q8BWW4
Go to UniProtKB:  Q8BWW4
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ8BWW4
Sequence Annotations
Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.46 Å
  • R-Value Free:  0.259 (Depositor), 0.218 (DCC)
  • R-Value Work:  0.204 (Depositor), 0.205 (DCC)
  • R-Value Observed: 0.207 (Depositor)
Space Group: P 31 1 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 78.04α = 90
b = 78.04β = 90
c = 32.36γ = 120
Software Package:
Software NamePurpose
PHENIXrefinement
xia2data reduction
xia2data scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China32070777

Revision History  (Full details and data files)

  • Version 1.0: 2025-03-05
    Type: Initial release
  • Version 1.1: 2025-09-24
    Changes: Database references
