9LMH | pdb_00009lmh

Crystal structure of LooH in complex with FAD

PDB DOI: https://doi.org/10.2210/pdb9LMH/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Nocardiopsis flavescens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-01-19 Released: 2026-01-21
Deposition Author(s): Zhang, F., Li, Y.C., Zhu, Y., Wang, K., Chang, C.Y., Xu, Z.
Funding Organization(s): National Science Council (NSC, Taiwan), National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.44 Å
R-Value Free:
0.267 (Depositor), 0.271 (DCC)
R-Value Work:
0.206 (Depositor), 0.210 (DCC)
R-Value Observed:
0.209 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Crystal structure of LooH in complex with FAD

Zhang, F., Li, Y.C., Zhu, Y., Wang, K., Chang, C.Y., Xu, Z.

To be published.

Macromolecule Content

Total Structure Weight: 126.12 kDa
Atom Count: 8,684
Modeled Residue Count: 1,054
Deposited Residue Count: 1,100
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
LooH	A, B	550	Nocardiopsis flavescens	Mutation(s): 0
UniProt
Find proteins for A0A6M5K9A4 (Nocardiopsis flavescens) Explore A0A6M5K9A4 Go to UniProtKB: A0A6M5K9A4
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A6M5K9A4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
FAD (Subject of Investigation/LOI) Query on FAD Download Ideal Coordinates CCD File SDF format, chain C [auth A] SDF format, chain D [auth B] MOL2 format, chain C [auth A] MOL2 format, chain D [auth B] mmCIF format, chain C [auth A] mmCIF format, chain D [auth B]	C [auth A], D [auth B]	FLAVIN-ADENINE DINUCLEOTIDE C₂₇ H₃₃ N₉ O₁₅ P₂ VWWQXMAJTJZDQX-UYBVJOGSSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.44 Å
R-Value Free: 0.267 (Depositor), 0.271 (DCC)
R-Value Work: 0.206 (Depositor), 0.210 (DCC)
R-Value Observed: 0.209 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 92.296	α = 90
b = 101.622	β = 90
c = 125.769	γ = 90

Software Package:

Software Name	Purpose
REFMAC	refinement
SCALA	data scaling
HKL-2000	data reduction
MOLREP	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2026-01-21

Deposition Author(s):

Funding Organization	Location	Grant Number
National Science Council (NSC, Taiwan)	Taiwan	--
National Natural Science Foundation of China (NSFC)	China	22107008, 81973197, and 81991525

Revision History (Full details and data files)

Version 1.0: 2026-01-21
Type: Initial release
