9L1I | pdb_00009l1i

Crystal structure of PpRib7 in complex with NADPH (P212121 form)

PDB DOI: https://doi.org/10.2210/pdb9L1I/pdb

Classification: BIOSYNTHETIC PROTEIN
Organism(s): Komagataella pastoris
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-12-14 Released: 2025-12-17
Deposition Author(s): Chen, S.C.
Funding Organization(s): National Science Council (NSC, Taiwan)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.08 Å
R-Value Free:
0.253 (Depositor), 0.252 (DCC)
R-Value Work:
0.199 (Depositor), 0.199 (DCC)
R-Value Observed:
0.201 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Ligand Structure Quality Assessment

This is version 1.0 of the entry. See complete history.

Literature

Divergence of RibG/Rib7 reductases in riboflavin biosynthesis: A study of Pichia pastoris Rib7 reductase

Chen, S.C.

To be published.

Macromolecule Content

Total Structure Weight: 56.9 kDa
Atom Count: 3,998
Modeled Residue Count: 486
Deposited Residue Count: 502
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
2,5-diamino-6-ribosylamino-4(3H)-pyrimidinone 5'-phosphate reductase	A, B	251	Komagataella pastoris	Mutation(s): 0 Gene Names: RIB7, PP7435_Chr3-1080 EC: 1.1.1.302
UniProt
Find proteins for F2QX95 (Komagataella phaffii (strain ATCC 76273 / CBS 7435 / CECT 11047 / NRRL Y-11430 / Wegner 21-1)) Explore F2QX95 Go to UniProtKB: F2QX95
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	F2QX95
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
NAP (Subject of Investigation/LOI) Query on NAP Download Ideal Coordinates CCD File SDF format, chain D [auth B] SDF format, chain C [auth A] MOL2 format, chain D [auth B] MOL2 format, chain C [auth A] mmCIF format, chain D [auth B] mmCIF format, chain C [auth A]	C [auth A], D [auth B]	NADP NICOTINAMIDE-ADENINE-DINUCLEOTIDE PHOSPHATE C₂₁ H₂₈ N₇ O₁₇ P₃ XJLXINKUBYWONI-NNYOXOHSSA-N		Interactions Focus chain C [auth A] Focus chain D [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth B]

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.08 Å
R-Value Free: 0.253 (Depositor), 0.252 (DCC)
R-Value Work: 0.199 (Depositor), 0.199 (DCC)
R-Value Observed: 0.201 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 47.217	α = 90
b = 79.439	β = 90
c = 139.165	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Ligand Structure Quality Assessment

Entry History & Funding Information

Deposition Data

Released Date: 2025-12-17

Deposition Author(s):

Funding Organization	Location	Grant Number
National Science Council (NSC, Taiwan)	Taiwan	NSTC 113 2311 B 992 001

Revision History (Full details and data files)

Version 1.0: 2025-12-17
Type: Initial release
