9KWZ | pdb_00009kwz

Cryo-EM structure of the ICT01-BTN2A1/BTN3A1/BTN3A2 complex

PDB DOI: https://doi.org/10.2210/pdb9KWZ/pdb
EM Map EMD-62622: EMDB EMDataResource

Classification: IMMUNE SYSTEM
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No

Deposited: 2024-12-06 Released: 2025-12-17
Deposition Author(s): Xin, W.Z., Huang, B.D., Zhou, Q.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.70 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9KWZ

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of the ICT01-BTN2A1/BTN3A1/BTN3A2 complex at 3.7 Angstroms reolution

Xin, W.Z., Huang, B.D., Zhou, Q.

To be published.

Macromolecule Content

Total Structure Weight: 272.4 kDa
Atom Count: 10,022
Modeled Residue Count: 1,304
Deposited Residue Count: 2,438
Unique protein chains: 5

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Butyrophilin subfamily 2 member A1	A, B	534	Homo sapiens	Mutation(s): 0 Gene Names: BTN2A1, BT2.1, BTF1
UniProt & NIH Common Fund Data Resources
Find proteins for Q7KYR7 (Homo sapiens) Explore Q7KYR7 Go to UniProtKB: Q7KYR7
PHAROS: Q7KYR7 GTEx: ENSG00000112763
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q7KYR7
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Butyrophilin subfamily 3 member A2	C [auth E]	340	Homo sapiens	Mutation(s): 0 Gene Names: BTN3A2, BT3.2, BTF3, BTF4
UniProt & NIH Common Fund Data Resources
Find proteins for P78410 (Homo sapiens) Explore P78410 Go to UniProtKB: P78410
PHAROS: P78410 GTEx: ENSG00000186470
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P78410
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Butyrophilin subfamily 3 member A1	D [auth F]	539	Homo sapiens	Mutation(s): 0 Gene Names: BTN3A1, BTF5
UniProt & NIH Common Fund Data Resources
Find proteins for O00481 (Homo sapiens) Explore O00481 Go to UniProtKB: O00481
PHAROS: O00481 GTEx: ENSG00000026950
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	O00481
Sequence Annotations Expand
Reference Sequence

Find similar proteins by:

Entity ID: 4
Molecule	Chains	Sequence Length	Organism	Details	Image
ICT01 heavy chain	E [auth H]	255	Homo sapiens	Mutation(s): 0

Find similar proteins by:

Entity ID: 5
Molecule	Chains	Sequence Length	Organism	Details	Image
ICT01 light chain	F [auth L]	236	Homo sapiens	Mutation(s): 0

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.70 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	RELION	5
MODEL REFINEMENT	EMAN2	2.99.62

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-12-17

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32100975

Revision History (Full details and data files)

Version 1.0: 2025-12-17
Type: Initial release
