9KT2 | pdb_00009kt2

The crystal structure of BD1 in complex with BDS4

• PDB DOI: https://doi.org/10.2210/pdb9KT2/pdb

• Classification: UNKNOWN FUNCTION
• Organism(s): Homo sapiens
• Expression System: Escherichia coli
• Mutation(s): No


• Deposited: 2024-12-01 Released: 2025-12-03
• Deposition Author(s): Zhang, Z.M., Wang, Y.Q.
• Funding Organization(s): Not funded

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.46 Å
• R-Value Free:
  0.195 (Depositor), 0.199 (DCC)
• R-Value Work:
  0.166 (Depositor), 0.173 (DCC)
• R-Value Observed:
  0.169 (Depositor)

Starting Model: experimental

Literature

Inhibition of BD1 of the BET proteins through covalent modification of lysine in living cells and animals

Zhang, Z.M., Wang, Y.Q.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors.

Biological Assembly Evidence: mass spectrometry

Macromolecule Content

• Total Structure Weight: 15.49 kDa
• Atom Count: 1,227
• Modeled Residue Count: 126
• Deposited Residue Count: 126
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Bromodomain-containing protein 4	A	126	Homo sapiens	Mutation(s): 0  Gene Names: BRD4, HUNK1
UniProt & NIH Common Fund Data Resources
Find proteins for O60885 (Homo sapiens) Explore O60885  Go to UniProtKB:  O60885
PHAROS:  O60885 GTEx:  ENSG00000141867

Small Molecules

Modified Residues  1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
A1EMP	A	L-PEPTIDE LINKING	C34 H36 N6 O4		LYS

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.46 Å
• R-Value Free:  0.195 (Depositor), 0.199 (DCC)
• R-Value Work:  0.166 (Depositor), 0.173 (DCC)
• R-Value Observed: 0.169 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 35.114	α = 90
b = 55.444	β = 90
c = 57.53	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-2000	data reduction
HKL-2000	data scaling
Coot	model building

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-12-03
Deposition Author(s): Zhang, Z.M., Wang, Y.Q.

---

Funding Organization	Location	Grant Number
Not funded		--

Revision History

• Version 1.0: 2025-12-03
  Type: Initial release
