9KSG | pdb_00009ksg

Crystal structure of RxLR145 effector

PDB DOI: https://doi.org/10.2210/pdb9KSG/pdb

Classification: CYTOSOLIC PROTEIN
Organism(s): Phytophthora capsici
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-11-29 Released: 2025-12-03
Deposition Author(s): Zhang, X.G.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.58 Å
R-Value Free:
0.289 (Depositor), 0.291 (DCC)
R-Value Work:
0.219 (Depositor), 0.226 (DCC)
R-Value Observed:
0.223 (Depositor)

wwPDB Validation 3D Report Full Report

Validation slider image for 9KSG

This is version 1.0 of the entry. See complete history.

Literature

A Phytophthora effector ensures infection by initial suppression of pattern triggered immunity, and timed activation of pattern and effector triggered immunity

Zhang, X.G.

To be published.

Macromolecule Content

Total Structure Weight: 110.27 kDa
Atom Count: 6,631
Modeled Residue Count: 815
Deposited Residue Count: 956
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
RXLR effector Avh1	A, B	478	Phytophthora capsici	Mutation(s): 0
UniProt
Find proteins for A0A678WQQ4 (Phytophthora capsici) Explore A0A678WQQ4 Go to UniProtKB: A0A678WQQ4
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	A0A678WQQ4
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
MSE Query on MSE	A, B	L-PEPTIDE LINKING	C₅ H₁₁ N O₂ Se		MET

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.58 Å
R-Value Free: 0.289 (Depositor), 0.291 (DCC)
R-Value Work: 0.219 (Depositor), 0.226 (DCC)
R-Value Observed: 0.223 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 71.034	α = 90
b = 89.587	β = 90
c = 147.716	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
HKL-3000	data reduction
HKL-3000	data scaling
SOLVE	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-12-03

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2025-12-03
Type: Initial release
