9KS5 | pdb_00009ks5

The crystal structure of ABL1 in complex with K-CNBA-1


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:
    0.212 (Depositor), 0.214 (DCC)
  • R-Value Work:
    0.170 (Depositor), 0.184 (DCC)
  • R-Value Observed:
    0.172 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


This is version 1.1 of the entry. See complete history


Literature

O -Cyanobenzaldehydes Irreversibly Modify Both Buried and Exposed Lysine Residues in Live Cells.

Ling, H.Li, L.Duan, L.Huang, W.Zheng, J.Zhang, S.Li, X.Qiu, X.Zhou, Y.Ma, N.Ren, X.Zhang, J.Wang, Z.Zhao, Y.Tian, R.Zhang, Z.M.Ding, K.

(2025) J Am Chem Soc 147: 11955-11963

  • DOI: https://doi.org/10.1021/jacs.4c18006
  • Primary Citation of Related Structures:
    9KS5, 9KS6

  • PubMed Abstract:

    Lysine residue represents an attractive site for covalent drug development due to its high abundance (5.6%) and critical functions. However, very few lysines have been characterized to be accessible to covalent ligands and perturb the protein functions, owing to their protonation state and adjacent steric hindrance. Herein, we report a new lysine bioconjugation chemistry, O -cyanobenzaldehyde (CNBA), that enables selective modification of the lysine ε-amine to form iso-indolinones under physiological conditions. Activity-based proteome profiling enabled the mapping of 3451 lysine residues and 85 endogenous kinases in live cells, highlighting its potential for modifying hyper-reactive lysines within the proteome or buried catalytic lysines within the kinome. Further protein crystallography and mass spectrometry confirmed that K271_ABL1 and K162_AURKA are covalently targetable sites in kinases. Leveraging a structure-based drug design, we incorporated CNBA into the core structure of Nutlin-3 to irreversibly inhibit the MDM2-p53 interaction by targeting an exposed lysine K94 on the surface of murine double minute 2. Importantly, we have demonstrated the potential application of CNBA as a lysine-recognized bioconjugation agent for developing new antibody-drug conjugates. The results collectively validate CNBA as a new selective and efficient modifying agent with broad applications for both buried and exposed lysine residues in live cells.


  • Organizational Affiliation
    • State Key Laboratory of Chemical Biology, Shanghai Institute of Organic Chemistry, Chinese Academy of Sciences, #345 Lingling Road, Shanghai 200032, China.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Tyrosine-protein kinase ABL1
A, B
272Homo sapiensMutation(s): 0
Gene Names: ABL1ABLJTK7
EC: 2.7.10.2
UniProt & NIH Common Fund Data Resources
Find proteins for P00519 (Homo sapiens)
Explore P00519
Go to UniProtKB:  P00519
PHAROS:  P00519
GTEx:  ENSG00000097007
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP00519
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Modified Residues  2 Unique
IDChains TypeFormula2D DiagramParent
A1EG1
Query on A1EG1
A, B
L-PEPTIDE LINKINGC33 H41 N11 O4LYS
PTR
Query on PTR
A, B
L-PEPTIDE LINKINGC9 H12 N O6 PTYR
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.20 Å
  • R-Value Free:  0.212 (Depositor), 0.214 (DCC)
  • R-Value Work:  0.170 (Depositor), 0.184 (DCC)
  • R-Value Observed: 0.172 (Depositor)
Space Group: P 21 21 2
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 106.48α = 90
b = 134.99β = 90
c = 58γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-3000data reduction
HKL-3000data scaling
Cootmodel building
PHASERphasing

Structure Validation

View Full Validation Report



Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-12-03
    Type: Initial release
  • Version 1.1: 2025-12-24
    Changes: Database references
