9KKU | pdb_00009kku

Helix-loop-helix peptide (M49) in complex with VEGF-A


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.46 Å
  • R-Value Free:
    0.250 (Depositor), 0.259 (DCC)
  • R-Value Work:
    0.217 (Depositor), 0.226 (DCC)
  • R-Value Observed:
    0.219 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9KKU

This is version 1.0 of the entry. See complete history

Literature

Structural Insights into Helix-Loop-Helix Peptides for "Ligand-Targeting" Intracellular Drug Delivery via VEGF Receptor-Mediated Endocytosis.

Michigami, M.Kira, R.Kamo, M.Hirokawa, T.Kinoshita, T.Inaka, K.Nakase, I.Fujii, I.

(2024) Biochem Biophys Res Commun 741: 150980-150980

  • DOI: https://doi.org/10.1016/j.bbrc.2024.150980
  • Primary Citation Related Structures:
    9KKU

  • PubMed Abstract:

    As a new alternative to antibody-drug conjugates, we developed "ligand-targeting" peptide-drug conjugates (PDCs), in which conformationally constrained helix-loop-helix (HLH) peptide M49 targeting human vascular endothelial growth factor-A (VEGF) was used as a drug carrier. The biochemical study showed that HLH peptide M49 made a complex with VEGF in the extracellular environment, and then the M49/VEGF complex interacts with the receptor on the cell surface to induce cellular internalization via the endocytic pathway. Here, we present an X-ray crystal structure of the M49/VEGF complex at 1.5 Å resolution using a protein crystal grown in microgravity. The structure illustrated the "ligand-targeting" cellular uptake mechanism for intracellular drug delivery and the molecular basis on the peptide-VEGF binding mode with tight binding and high target specificity. In addition, mutational studies and thermodynamic analysis provided information on the driving forces of the complex formation. This work would contribute to the design of mid-size molecular-targeting peptides as well as HLH peptides, advancing the research in drug discovery and chemical biology.


  • Organizational Affiliation
    • Department of Biological Chemistry, Graduate School of Science, Osaka Metropolitan University, 1-1 Gakuen-cho, Naka-ku, Sakai, Osaka, 599-8531, Japan.

Macromolecule Content

  • Total Structure Weight: 33.28 kDa
  • Atom Count: 2,357
  • Modeled Residue Count: 276
  • Deposited Residue Count: 290
  • Unique protein chains: 2

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Vascular endothelial growth factor A, long form
A, B
102Homo sapiensMutation(s): 0
Gene Names: VEGFAVEGF
UniProt & NIH Common Fund Data Resources
Find proteins for P15692 (Homo sapiens)
Explore P15692
Go to UniProtKB:  P15692
PHAROS:  P15692
GTEx:  ENSG00000112715
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupP15692
Sequence Annotations
Expand
Reference Sequence
Find similar proteins by:|  3D Structure
Entity ID: 2
MoleculeChains  Sequence LengthOrganismDetailsImage
M49
C, D
43synthetic constructMutation(s): 0

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.46 Å
  • R-Value Free:  0.250 (Depositor), 0.259 (DCC)
  • R-Value Work:  0.217 (Depositor), 0.226 (DCC)
  • R-Value Observed: 0.219 (Depositor)
Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 56.26α = 90
b = 66.42β = 90
c = 76.36γ = 90
Software Package:
Software NamePurpose
REFMACrefinement
Aimlessdata scaling
XDSdata reduction
MOLREPphasing

Structure Validation

View Full Validation Report



Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Japan Agency for Medical Research and Development (AMED)JapanJP24am121036

Revision History  (Full details and data files)

  • Version 1.0: 2024-12-11
    Type: Initial release
