9KEO | pdb_00009keo

Crystal Structure of HdNadV and its complex with NAM

• PDB DOI: https://doi.org/10.2210/pdb9KEO/pdb

• Classification: TRANSFERASE
• Organism(s): [Haemophilus] ducreyi
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): No


• Deposited: 2024-11-05 Released: 2025-11-12
• Deposition Author(s): Lin, T., ZhengJuan, W., Jia, Y.
• Funding Organization(s): National Natural Science Foundation of China (NSFC)

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 2.62 Å
• R-Value Free:
  0.228 (Depositor), 0.229 (DCC)
• R-Value Work:
  0.192 (Depositor), 0.194 (DCC)
• R-Value Observed:
  0.194 (Depositor)

Starting Model: in silico

Literature

The Structural Basis of NMN Synthesis Catalyzed by NadV from Haemophilus ducreyi

Lin, T., ZhengJuan, W., Jia, Y.

To be published.

Biological Assembly 1

Global Symmetry: Cyclic - C2  (Explore in 3D)
Global Stoichiometry: Homo 2-mer - A2

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 111.88 kDa
• Atom Count: 7,752
• Modeled Residue Count: 957
• Deposited Residue Count: 990
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Nicotinamide phosphoribosyltransferase	A, B	495	[Haemophilus] ducreyi	Mutation(s): 0  Gene Names: nadV, PNAD10009, RZ57_05785 EC: 2.4.2.12
UniProt
Find proteins for G1U9V7 (Haemophilus ducreyi) Explore G1U9V7  Go to UniProtKB:  G1U9V7

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
NCA (Subject of Investigation/LOI)	C [auth A], D [auth A], E [auth B], F [auth B]	NICOTINAMIDE C6 H6 N2 O DFPAKSUCGFBDDF-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 2.62 Å
• R-Value Free:  0.228 (Depositor), 0.229 (DCC)
• R-Value Work:  0.192 (Depositor), 0.194 (DCC)
• R-Value Observed: 0.194 (Depositor)

Space Group: P 6₅

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 160.82	α = 90
b = 160.82	β = 90
c = 129.79	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
Aimless	data scaling
MOLREP	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2025-11-12
Deposition Author(s): Lin, T., ZhengJuan, W., Jia, Y.

---

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History

• Version 1.0: 2025-11-12
  Type: Initial release
