9K1P | pdb_00009k1p

crystal structure of Rtks- C2221

PDB DOI: https://doi.org/10.2210/pdb9K1P/pdb

Classification: SIGNALING PROTEIN
Organism(s): Serratia marcescens
Expression System: Escherichia coli
Mutation(s): No

Deposited: 2024-10-16 Released: 2025-10-22
Deposition Author(s): Xu, M., Ran, T., Wang, W.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.89 Å
R-Value Free:
0.272 (Depositor), 0.266 (DCC)
R-Value Work:
0.226 (Depositor), 0.246 (DCC)
R-Value Observed:
0.228 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9K1P

This is version 1.0 of the entry. See complete history.

Literature

crystal structure of Rtks

Xu, M., Ran, T., Wang, W.

To be published.

Macromolecule Content

Total Structure Weight: 195.4 kDa
Atom Count: 12,491
Modeled Residue Count: 1,659
Deposited Residue Count: 1,816
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Type VI secretion system-associated protein	A, B, C, D, E A, B, C, D, E, F, G, H	227	Serratia marcescens	Mutation(s): 0 Gene Names: DMW43_01670, I8391_000023

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.89 Å
R-Value Free: 0.272 (Depositor), 0.266 (DCC)
R-Value Work: 0.226 (Depositor), 0.246 (DCC)
R-Value Observed: 0.228 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 153.721	α = 90
b = 228.332	β = 90
c = 151.623	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
SCALA	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-10-22

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	31770074

Revision History (Full details and data files)

Version 1.0: 2025-10-22
Type: Initial release
