9K06 | pdb_00009k06

Crystal structure of Pyrococcus abyssi AIR synthetase with residues 51-54 replaced by Neisseria gonorrhoeae residues 49-56


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:
    0.196 (Depositor), 0.196 (DCC)
  • R-Value Work:
    0.168 (Depositor), 0.168 (DCC)
  • R-Value Observed:
    0.169 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Structural insights into substrate binding, domain swapping and heat resistance of a hyperthermostable archaeal AIR synthetase.

Chen, Y.H.Huang, Y.C.Rao, R.G.R.Chang, H.C.Lan, Y.H.Nakagawa, A.Jeyaraman, J.Chen, C.J.

(2026) Int J Biol Macromol 344: 150493-150493

  • DOI: https://doi.org/10.1016/j.ijbiomac.2026.150493
  • Primary Citation of Related Structures:
    9JZW, 9JZX, 9JZY, 9JZZ, 9K00, 9K01, 9K02, 9K03, 9K04, 9K05, 9K06, 9VNU, 9VNV, 9VNW

  • PubMed Abstract:

    The enzyme 5-aminoimidazole ribonucleotide synthetase (AIR synthetase, AIRS, known also as PurM) catalyzes the fifth step in the de novo purine biosynthetic pathway: the ATP-dependent conversion of formylglycinamidine ribonucleotide (FGAM) to aminoimidazole ribonucleotide (AIR). AIRS belongs to the PurM superfamily, sharing ATPase domains. In this study, we employed hyperthermostable AIRS from Pyrococcus abyssi (Pa) and Pyrococcus horikoshii (Ph), members of the thermophilic archaeal genus known for extreme heat tolerance, to resolve the substrate-binding site and structural features. Crystal structures of AIRS were determined in complex with the substrate analog formylglycinamide ribonucleotide (FGAR), the non-hydrolyzable ATP analog adenylyl-imidodiphosphate (AMPPNP), the product ADP, and metal cofactors (Mn 2+ , Mg 2+ , and K + ), respectively. AMPPNP and FGAR bind to the α1-β1 loop and the disordered N-terminal tail, respectively, stabilizing the active-site conformation. These findings provide a structural framework for understanding substrate positioning and catalysis within AIRS. A unique non-domain-swapping feature observed in the first 54 residues of the N-terminal domain in PaAIRS and PhAIRS, differing from their orthologs. The domain-swappable feature is found to be β1-β2 loop-dependent and can be categorized into two distinct types in the AIRS family: a short-looped, non-swapping archaeal type and a long-looped, swapping bacterial type. Structural, mutational, and biophysical analyses suggest that the thermostability is supported by enhanced hydrophobic core packing, strengthened dimer interfaces, and shortened surface loops. Collectively, these findings not only elucidate the substrate binding, the catalytic mechanism, and domain swapping of AIRS but also contribute to our understanding of the compact and robust architecture characteristics of thermophilic proteins.


  • Organizational Affiliation
    • Life Science Group, Scientific Research Division, National Synchrotron Radiation Research Center, Hsinchu, 300092, Taiwan.

Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Phosphoribosylformylglycinamidine cyclo-ligase
A, B
325Pyrococcus abyssi GE5Mutation(s): 2
Gene Names: purMPYRAB16520PAB1083
EC: 6.3.3.1
UniProt
Find proteins for Q9UY56 (Pyrococcus abyssi (strain GE5 / Orsay))
Explore Q9UY56
Go to UniProtKB:  Q9UY56
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupQ9UY56
Sequence Annotations
Expand
  • Reference Sequence
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 1.70 Å
  • R-Value Free:  0.196 (Depositor), 0.196 (DCC)
  • R-Value Work:  0.168 (Depositor), 0.168 (DCC)
  • R-Value Observed: 0.169 (Depositor)
Space Group: C 1 2 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 104.905α = 90
b = 112.79β = 107.074
c = 70.906γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
XDSdata reduction
XDSdata scaling
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Science Council (NSC, Taiwan)Taiwan--

Revision History  (Full details and data files)

  • Version 1.0: 2025-10-15
    Type: Initial release
  • Version 1.1: 2026-02-11
    Changes: Database references
