9JUF | pdb_00009juf

PEDV 3CLpro mutant (C144A) in complex with nsp9|10 peptidyl substrate

PDB DOI: https://doi.org/10.2210/pdb9JUF/pdb

Classification: VIRAL PROTEIN
Organism(s): Porcine epidemic diarrhea virus
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2024-10-08 Released: 2025-10-22
Deposition Author(s): Zhang, Y., Liang, R., Shi, Y.J., Peng, G.Q.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free:
0.238 (Depositor), 0.240 (DCC)
R-Value Work:
0.196 (Depositor), 0.198 (DCC)
R-Value Observed:
0.198 (Depositor)

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

PEDV 3CLpro mutant (C144A) in complex with nsp9|10 peptidyl substrate

Zhang, Y., Liang, R., Shi, Y.J., Peng, G.Q.

To be published.

Macromolecule Content

Total Structure Weight: 70.1 kDa
Atom Count: 4,937
Modeled Residue Count: 606
Deposited Residue Count: 640
Unique protein chains: 2

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ORF1ab polyprotein	A, B	310	Porcine epidemic diarrhea virus	Mutation(s): 1
UniProt
Find proteins for A0A023J7B5 (Porcine epidemic diarrhea virus) Explore A0A023J7B5 Go to UniProtKB: A0A023J7B5
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	A0A023J7B5
Sequence Annotations Expand
Reference Sequence

Find similar proteins by: Sequence | 3D Structure

Entity ID: 2
Molecule	Chains	Sequence Length	Organism	Details	Image
Replicase polyprotein 1a	C, D	10	Porcine epidemic diarrhea virus	Mutation(s): 0
UniProt
Find proteins for P0C6V6 (Porcine epidemic diarrhea virus (strain CV777)) Explore P0C6V6 Go to UniProtKB: P0C6V6
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	P0C6V6
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.95 Å
R-Value Free: 0.238 (Depositor), 0.240 (DCC)
R-Value Work: 0.196 (Depositor), 0.198 (DCC)
R-Value Observed: 0.198 (Depositor)

Space Group: P 1 2₁ 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 57.001	α = 90
b = 91.096	β = 99.98
c = 57.944	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
AUTOMAR	data reduction
xia2	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-10-22

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	--

Revision History (Full details and data files)

Version 1.0: 2025-10-22
Type: Initial release
