9JJ1 | pdb_00009jj1

Cryo-EM structure of human ZnT3

PDB DOI: https://doi.org/10.2210/pdb9JJ1/pdb
EM Map EMD-61514: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Expression System: Homo sapiens
Mutation(s): No
Membrane Protein: Yes MemProtMD

Deposited: 2024-09-12 Released: 2025-06-04
Deposition Author(s): Ishida, H., Yo, R., Zhnag, Z., Shimizu, T., Ohto, U.
Funding Organization(s): Ministry of Education, Culture, Sports, Science and Technology (Japan)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.72 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

Structural basis for the zinc transporters, ZnT3 and ZnT4

Ishida, H., Yo, R., Zhang, Z., Shimizu, T., Ohto, U.

To be published.

Macromolecule Content

Total Structure Weight: 90.26 kDa
Atom Count: 4,842
Modeled Residue Count: 614
Deposited Residue Count: 810
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Probable proton-coupled zinc antiporter SLC30A3	A, B	405	Homo sapiens	Mutation(s): 0 Gene Names: SLC30A3, ZNT3 Membrane Entity: Yes
UniProt & NIH Common Fund Data Resources
Find proteins for Q99726 (Homo sapiens) Explore Q99726 Go to UniProtKB: Q99726
PHAROS: Q99726 GTEx: ENSG00000115194
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Group	Q99726
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 2 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
AV0 Query on AV0 Download Ideal Coordinates CCD File SDF format, chain J [auth B] SDF format, chain E [auth A] MOL2 format, chain J [auth B] MOL2 format, chain E [auth A] mmCIF format, chain J [auth B] mmCIF format, chain E [auth A]	E [auth A], J [auth B]	Lauryl Maltose Neopentyl Glycol C₄₇ H₈₈ O₂₂ MADJBYLAYPCCOO-VWHTXWAPSA-N		Interactions Focus chain E [auth A] Focus chain J [auth B] Interactions & Density Focus chain E [auth A] Focus chain J [auth B]
ZN Query on ZN Download Ideal Coordinates CCD File SDF format, chain I [auth B] SDF format, chain H [auth B] SDF format, chain G [auth B] SDF format, chain F [auth A] SDF format, chain D [auth A] SDF format, chain C [auth A] MOL2 format, chain I [auth B] MOL2 format, chain H [auth B] MOL2 format, chain G [auth B] MOL2 format, chain F [auth A] MOL2 format, chain D [auth A] MOL2 format, chain C [auth A] mmCIF format, chain I [auth B] mmCIF format, chain H [auth B] mmCIF format, chain G [auth B] mmCIF format, chain F [auth A] mmCIF format, chain D [auth A] mmCIF format, chain C [auth A]	C [auth A] D [auth A] F [auth A] G [auth B] H [auth B] C [auth A], D [auth A], F [auth A], G [auth B], H [auth B], I [auth B]	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain C [auth A] Focus chain D [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B] Interactions & Density Focus chain C [auth A] Focus chain D [auth A] Focus chain F [auth A] Focus chain G [auth B] Focus chain H [auth B] Focus chain I [auth B]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.72 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1_4487:

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2025-06-04

Deposition Author(s):

Funding Organization	Location	Grant Number
Ministry of Education, Culture, Sports, Science and Technology (Japan)	Japan	20K16274 and 22K07131 (H.I.); 22K15046 and 24K09349 (Z.Z.); 19H00976, 22H05184, and 23H00366 (T.S.); and 19H03164 and 22H02556 [U.O.)
