9JDN | pdb_00009jdn

Crystal structure of alanyl-tRNA synthetase L219M mutant in complex with ATP and L-alanine


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.18 Å
  • R-Value Free:
    0.234 (Depositor), 0.235 (DCC)
  • R-Value Work:
    0.201 (Depositor), 0.201 (DCC)
  • R-Value Observed:
    0.203 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9JDN

Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history

Literature

Unlocking the serine mischarging paradox and inhibiting lactyltransferase activity of AlaRS by a single-point mutation.

Park, W.Son, S.Y.Yi, J.Cha, S.Moon, H.Kim, M.Ji, S.Yu, W.Sung, C.Cha, S.S.Hahn, J.S.

(2025) Nucleic Acids Res 53

  • DOI: https://doi.org/10.1093/nar/gkaf462
  • Primary Citation Related Structures:
    9JC7, 9JDN

  • PubMed Abstract:

    Aminoacyl-tRNA synthetases are critical for accurate genetic translation, attaching amino acids to their corresponding transfer RNA molecules. Alanyl-tRNA synthetase (AlaRS) often misactivates Ser or Gly instead of Ala, which is detrimental unless corrected by its editing functions. The paradox of misactivating larger Ser by AlaRS was considered inevitable due to its inherent design, sharing an essential acidic residue to accommodate the activated adenylated intermediates from both cognate and non-cognate amino acids. Here we show a groundbreaking discovery where a single-point mutation, L219M, in AlaRS from Methylomonas sp. DH-1, effectively eliminates Ser misactivation. Structural analysis of the pre-activation state unveiled that the flexibility of Val204 is the key to preventing Ser binding in AlaRSL219M. This research elucidates the amino acid discrimination mechanism in AlaRS, independent of editing domain. Remarkably, the AlaRSL219M mutation was initially identified as a causal mutation enhancing lactate tolerance in a strain developed through adaptive laboratory evolution. We showed that AlaRSL219M also eliminates the enzyme's inherent lactyltransferase activity, suggesting that the lactate tolerance observed might result from preventing excessive protein lactylation under lactate stress. This opens possibilities for developing high-fidelity and lactylation-deficient AlaRS mutants across various organisms, facilitating studies on their potential benefits in different physiological scenarios.


  • Organizational Affiliation
    • Department of Chemical and Biological Engineering, Institute of Chemical Processes, Seoul National University, Seoul 08826, Republic of Korea.

Macromolecule Content

  • Total Structure Weight: 100.05 kDa
  • Atom Count: 7,000
  • Modeled Residue Count: 845
  • Deposited Residue Count: 870
  • Unique protein chains: 1

Macromolecules

Find similar proteins by:|  3D Structure
Entity ID: 1
MoleculeChains  Sequence LengthOrganismDetailsImage
Alanine--tRNA ligase
A, B
435Methylomonas sp. DH-1Mutation(s): 1
Gene Names: alaS
EC: 6.1.1.7

Small Molecules

Ligands 5 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
ATP
(Subject of Investigation/LOI)

Query on ATP



Download:Ideal Coordinates CCD File
C [auth A],
G [auth A],
H [auth B]
ADENOSINE-5'-TRIPHOSPHATE
C10 H16 N5 O13 P3
ZKHQWZAMYRWXGA-KQYNXXCUSA-N
CIT

Query on CIT



Download:Ideal Coordinates CCD File
E [auth A],
M [auth B]
CITRIC ACID
C6 H8 O7
KRKNYBCHXYNGOX-UHFFFAOYSA-N
TRS

Query on TRS



Download:Ideal Coordinates CCD File
F [auth A],
L [auth B]
2-AMINO-2-HYDROXYMETHYL-PROPANE-1,3-DIOL
C4 H12 N O3
LENZDBCJOHFCAS-UHFFFAOYSA-O
GOL

Query on GOL



Download:Ideal Coordinates CCD File
J [auth B],
K [auth B],
N [auth B]
GLYCEROL
C3 H8 O3
PEDCQBHIVMGVHV-UHFFFAOYSA-N
ALA
(Subject of Investigation/LOI)

Query on ALA



Download:Ideal Coordinates CCD File
D [auth A],
I [auth B]
ALANINE
C3 H7 N O2
QNAYBMKLOCPYGJ-REOHCLBHSA-N

Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.18 Å
  • R-Value Free:  0.234 (Depositor), 0.235 (DCC)
  • R-Value Work:  0.201 (Depositor), 0.201 (DCC)
  • R-Value Observed: 0.203 (Depositor)
Space Group: P 1 21 1
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 78.84α = 90
b = 56.57β = 102.263
c = 125.63γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
PHENIXphasing
XDSdata reduction
XDSdata scaling

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History

& Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
Not funded--

Revision History  (Full details and data files)

  • Version 1.0: 2025-06-18
    Type: Initial release
  • Version 1.1: 2025-06-25
    Changes: Database references
