9JCS | pdb_00009jcs

Multidrug resistance-associated protein 2 in complex with MK-571

PDB DOI: https://doi.org/10.2210/pdb9JCS/pdb
EM Map EMD-61373: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Homo sapiens
Mutation(s): No

Deposited: 2024-08-30 Released: 2026-04-01
Deposition Author(s): Yun, C.H., Zhao, P.
Funding Organization(s): National Natural Science Foundation of China (NSFC)

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.47 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9JCS

This is version 1.0 of the entry. See complete history.

Literature

Multidrug resistance-associated protein 2 in complex with MK-571

Yun, C.H., Zhao, P.

To be published.

Macromolecule Content

Total Structure Weight: 174.91 kDa
Atom Count: 9,177
Modeled Residue Count: 1,338
Deposited Residue Count: 1,545
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
ATP-binding cassette sub-family C member 2	A	1,545	Homo sapiens	Mutation(s): 0 EC: 7.6.2 (PDB Primary Data), 7.6.2.2 (PDB Primary Data), 7.6.2.3 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for Q92887 (Homo sapiens) Explore Q92887 Go to UniProtKB: Q92887
PHAROS: Q92887 GTEx: ENSG00000023839
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q92887
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
A1EIX (Subject of Investigation/LOI) Query on A1EIX Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	3-[(~{S})-[3-[(~{E})-2-(7-chloranylquinolin-2-yl)ethenyl]phenyl]-[3-(dimethylamino)-3-oxidanylidene-propyl]sulfanyl-methyl]sulfanylpropanoic acid C₂₆ H₂₇ Cl N₂ O₃ S₂ AXUZQJFHDNNPFG-JORPFSLRSA-N		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.47 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
RECONSTRUCTION	cryoSPARC	4.6.2

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-04-01

Deposition Author(s):

Funding Organization	Location	Grant Number
National Natural Science Foundation of China (NSFC)	China	32471256

Revision History (Full details and data files)

Version 1.0: 2026-04-01
Type: Initial release
