9IZL

hVanin-1 complexed with X17


Experimental Data Snapshot

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.215
  • R-Value Observed: 0.217

Starting Model: experimental
View more details

wwPDB Validation   3D Report Full Report


Ligand Structure Quality Assessment


This is version 1.1 of the entry. See complete history


Literature

Discovery of Thiazole Carboxamides as Novel Vanin-1 Inhibitors for Inflammatory Bowel Disease Treatment.

Xie, T.Cao, G.Y.Zhang, S.Li, M.K.Jin, X.Liu, L.Wang, G.Zhen, L.

(2024) J Med Chem 67: 20372-20398

  • DOI: https://doi.org/10.1021/acs.jmedchem.4c01838
  • Primary Citation of Related Structures:
    9IZL

  • PubMed Abstract:

    Inflammatory bowel disease (IBD) is a clinically heterogeneous disease demanding more therapeutic targets and intervention strategies. Vanin-1, an oxidative stress-regulating protein, has emerged as a promising target for alleviating inflammation and oxidative stress. In this study, a series of thiazole carboxamide derivatives as vanin-1 inhibitors were designed and synthesized. The preferred compound, X17 , demonstrated potent inhibition against vanin-1 at the protein, HT-29 cell, and tissue levels, whose binding mode with the target was confirmed via the cocrystal structure. X17 achieved a high bioavailability of 81% in rats, accompanied by concentration-dependent inhibition of serum vanin-1. In a DSS-induced mouse colitis model, X17 exhibited potent anti-inflammatory and antioxidant activities, repressing the inflammatory factor expressions and myeloperoxidase activity, elevating the colonic glutathione reserve, and restoring the intestinal barrier. Collectively, these findings depict the discovery of a potent vanin-1 inhibitor, providing an opportunity for further drug candidate development for treating IBD.


  • Organizational Affiliation

    Key Laboratory of Drug Metabolism and Pharmacokinetics, China Pharmaceutical University, Nanjing, Jiangsu 210009, China.


Macromolecules
Find similar proteins by:  (by identity cutoff)  |  3D Structure
Entity ID: 1
MoleculeChains Sequence LengthOrganismDetailsImage
Pantetheinase
A, B
462Homo sapiensMutation(s): 1
Gene Names: VNN1
EC: 3.5.1.92
UniProt & NIH Common Fund Data Resources
Find proteins for O95497 (Homo sapiens)
Explore O95497
Go to UniProtKB:  O95497
PHAROS:  O95497
GTEx:  ENSG00000112299
Entity Groups
Sequence Clusters30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt GroupO95497
Sequence Annotations
Expand
  • Reference Sequence
Small Molecules
Ligands 1 Unique
IDChains Name / Formula / InChI Key2D Diagram3D Interactions
A1EAG (Subject of Investigation/LOI)
Query on A1EAG

Download Ideal Coordinates CCD File
C [auth A],
D [auth B]
8-oxa-2-azaspiro[4.5]decan-2-yl-[2-[(3~{S})-3-oxidanylpyrrolidin-1-yl]-1,3-thiazol-5-yl]methanone
C16 H23 N3 O3 S
PDHLSHPRWHXZMR-LBPRGKRZSA-N
Experimental Data & Validation

Experimental Data

  • Method: X-RAY DIFFRACTION
  • Resolution: 2.28 Å
  • R-Value Free: 0.260
  • R-Value Work: 0.215
  • R-Value Observed: 0.217
  • Space Group: P 21 21 21
Unit Cell:
Length ( Å )Angle ( ˚ )
a = 58.823α = 90
b = 92.98β = 90
c = 218.923γ = 90
Software Package:
Software NamePurpose
PHENIXrefinement
HKL-2000data scaling
HKL-2000data reduction
PHENIXphasing

Structure Validation

View Full Validation Report



Ligand Structure Quality Assessment


Entry History & Funding Information

Deposition Data


Funding OrganizationLocationGrant Number
National Natural Science Foundation of China (NSFC)China82173686

Revision History  (Full details and data files)

  • Version 1.0: 2024-12-04
    Type: Initial release
  • Version 1.1: 2024-12-11
    Changes: Database references
