9IUB | pdb_00009iub

Cryo-EM structure of the large serine recombinase Bxb1 in complex with attP and attB (GT/TT CDN) in the pre-strand exchange state (attB-R)

PDB DOI: https://doi.org/10.2210/pdb9IUB/pdb
EM Map EMD-60896: EMDB EMDataResource
NAKB: 9IUB

Classification: DNA BINDING PROTEIN
Organism(s): Mycolicibacterium smegmatis, Mycobacterium phage Bxb1
Expression System: Escherichia coli
Mutation(s): Yes

Deposited: 2024-07-20 Released: 2026-03-04
Deposition Author(s): Soma, T., Hiraizumi, M., Yamashita, K., Nishimasu, H.
Funding Organization(s): Japan Science and Technology

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 3.08 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

wwPDB Validation 3D Report Full Report

Validation slider image for 9IUB

This is version 1.0 of the entry. See complete history.

Literature

Cryo-EM structure of the large serine recombinase Bxb1 in complex with attP and attB (GT/TT CDN) in the pre-strand exchange state (attB-R)

Soma, T.

To be published.

Macromolecule Content

Total Structure Weight: 70.62 kDa
Atom Count: 3,346
Modeled Residue Count: 348
Deposited Residue Count: 546
Unique protein chains: 1
Unique nucleic acid chains: 2

Macromolecules

Find similar proteins by:

Entity ID: 3
Molecule	Chains	Sequence Length	Organism	Details	Image
Integrase	C [auth D]	500	Mycobacterium phage Bxb1	Mutation(s): 0 Gene Names: 35, PBI_BXB1_35
UniProt
Find proteins for Q9B086 (Mycobacterium phage Bxb1) Explore Q9B086 Go to UniProtKB: Q9B086
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9B086
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 1
attB-R	A [auth G2]	22	Mycolicibacterium smegmatis
Sequence Annotations Expand
Reference Sequence

Find similar nucleic acids by: Sequence

Molecule	Chains	Length	Organism	Image
Entity ID: 2
attB-R	B [auth H2]	24	Mycolicibacterium smegmatis
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
ZN (Subject of Investigation/LOI) Query on ZN Download:Ideal Coordinates CCD File SDF format, chain D MOL2 format, chain D mmCIF format, chain D	D	ZINC ION Zn PTFCDOFLOPIGGS-UHFFFAOYSA-N		Interactions Focus chain D Interactions & Density Focus chain D

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 3.08 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	Servalcat
RECONSTRUCTION	cryoSPARC

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-03-04

Deposition Author(s):

Funding Organization	Location	Grant Number
Japan Science and Technology	Japan	JPMJAX232F
Japan Science and Technology	Japan	JPMJCR23B6

Revision History (Full details and data files)

Version 1.0: 2026-03-04
Type: Initial release
