9IAE | pdb_00009iae

Structure of a Chimeric Protein Composed of the SNX5 PX Domain and the N-Terminal Region of NCOA7-AS, crystal form I

PDB DOI: https://doi.org/10.2210/pdb9IAE/pdb

Classification: UNKNOWN FUNCTION
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2025-02-10 Released: 2026-01-28
Deposition Author(s): Arnaud-Arnould, M., Rebendenne, A., Tauziet, M., Urbach, S., El Koulali, K., Ricci, E., Wencker, M., Moncorge, O., Blaise, M., Goujon, C.
Funding Organization(s): Agence Nationale de la Recherche (ANR), European Research Council (ERC)

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free:
0.240 (Depositor), 0.240 (DCC)
R-Value Work:
0.201 (Depositor), 0.201 (DCC)
R-Value Observed:
0.205 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

This is version 1.0 of the entry. See complete history.

Literature

SNX-BAR proteins 5 and 6 are required for NCOA7-AS antiviral activity against influenza A virus

Arnaud-Arnould, M., Rebendenne, A., Tauziet, M., Urbach, S., El Koulali, K., Ricci, E., Wencker, M., Moncorge, O., Blaise, M., Goujon, C.

(2025) bioRxiv

DOI: https://doi.org/10.1101/2025.04.01.646557

Macromolecule Content

Total Structure Weight: 20.7 kDa
Atom Count: 1,595
Modeled Residue Count: 173
Deposited Residue Count: 178
Unique protein chains: 1

Macromolecules

Find similar proteins by:

(by identity cutoff) | 3D Structure

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Sorting nexin-5,Nuclear receptor coactivator 7	A	178	Homo sapiens	Mutation(s): 0 Gene Names: SNX5, NCOA7
UniProt & NIH Common Fund Data Resources
Find proteins for H0Y6T0 (Homo sapiens) Explore H0Y6T0 Go to UniProtKB: H0Y6T0
GTEx: ENSG00000111912
Find proteins for Q9Y5X3 (Homo sapiens) Explore Q9Y5X3 Go to UniProtKB: Q9Y5X3
PHAROS: Q9Y5X3 GTEx: ENSG00000089006
Entity Groups
Sequence Clusters	30% Identity50% Identity70% Identity90% Identity95% Identity100% Identity
UniProt Groups	Q9Y5X3H0Y6T0
Sequence Annotations Expand
Reference Sequence

Small Molecules

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CME Query on CME	A	L-PEPTIDE LINKING	C₅ H₁₁ N O₃ S₂		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 2.30 Å
R-Value Free: 0.240 (Depositor), 0.240 (DCC)
R-Value Work: 0.201 (Depositor), 0.201 (DCC)
R-Value Observed: 0.205 (Depositor)

Space Group: P 3₂ 2 1

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 63.13	α = 90
b = 63.13	β = 90
c = 101.51	γ = 120

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
PHASER	phasing

Structure Validation

View Full Validation Report

Entry History & Funding Information

Deposition Data

Released Date: 2026-01-28

Deposition Author(s):

Arnaud-Arnould, M.

Funding Organization	Location	Grant Number
Agence Nationale de la Recherche (ANR)	France	ANR-20-CE15-0010-02
European Research Council (ERC)	European Union	759226

Revision History (Full details and data files)

Version 1.0: 2026-01-28
Type: Initial release
