9HWF | pdb_00009hwf

Isopenicillin N synthase N252E variant in complex with Fe and IPN after O2 exposure

• PDB DOI: https://doi.org/10.2210/pdb9HWF/pdb

• Classification: OXIDOREDUCTASE
• Organism(s): Aspergillus nidulans FGSC A4
• Expression System: Escherichia coli BL21(DE3)
• Mutation(s): Yes


• Deposited: 2025-01-03 Released: 2026-01-14
• Deposition Author(s): Rabe, P., Schofield, C.J., Stead, A.
• Funding Organization(s): Biotechnology and Biological Sciences Research Council (BBSRC), Wellcome Trust

---

Experimental Data Snapshot

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:
  0.203 (Depositor), 0.202 (DCC)
• R-Value Work:
  0.168 (Depositor), 0.168 (DCC)
• R-Value Observed:
  0.169 (Depositor)

Starting Model: experimental

Literature

Isopenicillin N synthase N252E variant in complex with Fe and IPN after O2 exposure

Rabe, P., Schofield, C.J., Stead, A.

To be published.

Biological Assembly 1

Global Symmetry: Asymmetric - C1
Global Stoichiometry: Monomer - A1

Biological assembly 1 assigned by authors and generated by PISA (software)

Biological Assembly Evidence: gel filtration

Macromolecule Content

• Total Structure Weight: 38.27 kDa
• Atom Count: 3,180
• Modeled Residue Count: 331
• Deposited Residue Count: 331
• Unique protein chains: 1

Macromolecules

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Isopenicillin N synthase	A	331	Aspergillus nidulans FGSC A4	Mutation(s): 1  Gene Names: ipnA, ips, AN2622 EC: 1.21.3.1
UniProt
Find proteins for P05326 (Emericella nidulans (strain FGSC A4 / ATCC 38163 / CBS 112.46 / NRRL 194 / M139)) Explore P05326  Go to UniProtKB:  P05326

Small Molecules

Ligands 3 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram
IP1 (Subject of Investigation/LOI)	F [auth A]	ISOPENICILLIN N C14 H21 N3 O6 S MIFYHUACUWQUKT-GTQWGBSQSA-N
SO4	C [auth A], D [auth A], E [auth A]	SULFATE ION O4 S QAOWNCQODCNURD-UHFFFAOYSA-L
FE (Subject of Investigation/LOI)	B [auth A]	FE (III) ION Fe VTLYFUHAOXGGBS-UHFFFAOYSA-N

Experimental Data & Validation

Experimental Data

• Method: X-RAY DIFFRACTION
• Resolution: 1.40 Å
• R-Value Free:  0.203 (Depositor), 0.202 (DCC)
• R-Value Work:  0.168 (Depositor), 0.168 (DCC)
• R-Value Observed: 0.169 (Depositor)

Space Group: P 2₁ 2₁ 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 41.339	α = 90
b = 74.398	β = 90
c = 101.283	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
xia2	data reduction
xia2	data scaling
PHASER	phasing

Structure Validation

Entry History & Funding Information

Deposition Data

• Released Date: 2026-01-14
Deposition Author(s): Rabe, P., Schofield, C.J., Stead, A.

---

Funding Organization	Location	Grant Number
Biotechnology and Biological Sciences Research Council (BBSRC)	United Kingdom	BB/V001892/1
Wellcome Trust	United Kingdom	210734/Z/18/Z
Wellcome Trust	United Kingdom	227298/Z/23/Z

Revision History

• Version 1.0: 2026-01-14
  Type: Initial release
