9HP3 | pdb_00009hp3

Orotidine 5'-monophosphate decarboxylase-domain of human UMPS in resting state at 1.2 Angstrom resolution

PDB DOI: https://doi.org/10.2210/pdb9HP3/pdb

Classification: LYASE
Organism(s): Homo sapiens
Expression System: Escherichia coli BL21(DE3)
Mutation(s): No

Deposited: 2024-12-12 Released: 2026-06-24
Deposition Author(s): Kirck, L.L., Tittmann, K.
Funding Organization(s): Not funded

Experimental Data Snapshot

Method: X-RAY DIFFRACTION
Resolution: 1.20 Å
R-Value Free:
0.175 (Depositor), 0.175 (DCC)
R-Value Work:
0.145 (Depositor), 0.146 (DCC)
R-Value Observed:
0.147 (Depositor)

Starting Model: experimental
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9HP3

This is version 1.0 of the entry. See complete history.

Literature

Orotidine 5'-monophosphate decarboxylase-domain of human UMPS in resting state at 1.2 Angstrom resolution

Kirck, L.L., Tittmann, K.

To be published.

Macromolecule Content

Total Structure Weight: 28.3 kDa
Atom Count: 2,431
Modeled Residue Count: 253
Deposited Residue Count: 258
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Uridine 5'-monophosphate synthase	A	258	Homo sapiens	Mutation(s): 0 Gene Names: UMPS, OK/SW-cl.21 EC: 2.4.2.10 (PDB Primary Data), 4.1.1.23 (PDB Primary Data)
UniProt & NIH Common Fund Data Resources
Find proteins for P11172 (Homo sapiens) Explore P11172 Go to UniProtKB: P11172
PHAROS: P11172 GTEx: ENSG00000114491
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	P11172
Sequence Annotations Expand
Reference Sequence

Small Molecules

Ligands 1 Unique
ID	Chains	Name / Formula / InChI Key	2D Diagram	3D Interactions
SO4 Query on SO4 Download:Ideal Coordinates CCD File SDF format, chain B [auth A] MOL2 format, chain B [auth A] mmCIF format, chain B [auth A]	B [auth A]	SULFATE ION O₄ S QAOWNCQODCNURD-UHFFFAOYSA-L		Interactions Focus chain B [auth A] Interactions & Density Focus chain B [auth A]

Modified Residues 1 Unique
ID	Chains	Type	Formula	2D Diagram	Parent
CSS Query on CSS	A	L-PEPTIDE LINKING	C₃ H₇ N O₂ S₂		CYS

Experimental Data & Validation

Experimental Data

Method: X-RAY DIFFRACTION
Resolution: 1.20 Å
R-Value Free: 0.175 (Depositor), 0.175 (DCC)
R-Value Work: 0.145 (Depositor), 0.146 (DCC)
R-Value Observed: 0.147 (Depositor)

Space Group: C 2 2 2₁

Unit Cell:

Length ( Å )	Angle ( ˚ )
a = 76.86	α = 90
b = 118.25	β = 90
c = 62.09	γ = 90

Software Package:

Software Name	Purpose
PHENIX	refinement
XDS	data reduction
XSCALE	data scaling
MOLREP	phasing

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2026-06-24

Deposition Author(s):

Funding Organization	Location	Grant Number
Not funded		--

Revision History (Full details and data files)

Version 1.0: 2026-06-24
Type: Initial release
