9HEZ | pdb_00009hez

CryoEM structure of mouse Panx1-R75A, wide conformation

PDB DOI: https://doi.org/10.2210/pdb9HEZ/pdb
EM Map EMD-52102: EMDB EMDataResource

Classification: MEMBRANE PROTEIN
Organism(s): Mus musculus
Expression System: Spodoptera frugiperda
Mutation(s): Yes

Deposited: 2024-11-14 Released: 2025-11-26
Deposition Author(s): Gaullier, G., Zhang, Q., Mim, C., Dahl, G.
Funding Organization(s): Carl Trygger Foundation

Experimental Data Snapshot

Method: ELECTRON MICROSCOPY
Resolution: 2.74 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

Starting Model: in silico
View more details

wwPDB Validation 3D Report Full Report

Validation slider image for 9HEZ

This is version 1.0 of the entry. See complete history.

Literature

Phosphorylation of Pannexin 1 activates ATP release

Zhang, Q., Gaullier, G., Dahl, G., Mim, C.

To be published.

Macromolecule Content

Total Structure Weight: 351.17 kDa
Atom Count: 17,934
Modeled Residue Count: 2,226
Deposited Residue Count: 3,108
Unique protein chains: 1

Macromolecules

Find similar proteins by:

Entity ID: 1
Molecule	Chains	Sequence Length	Organism	Details	Image
Pannexin-1	A, B, C, D, E A, B, C, D, E, F, G	444	Mus musculus	Mutation(s): 1 Gene Names: Panx1
UniProt & NIH Common Fund Data Resources
Find proteins for Q9JIP4 (Mus musculus) Explore Q9JIP4 Go to UniProtKB: Q9JIP4
IMPC: MGI:1860055
Entity Groups
Sequence Clusters	30% Identity 50% Identity 70% Identity 90% Identity 95% Identity 100% Identity
UniProt Group	Q9JIP4
Sequence Annotations Expand
Reference Sequence

Experimental Data & Validation

Experimental Data

Method: ELECTRON MICROSCOPY
Resolution: 2.74 Å
Aggregation State: PARTICLE
Reconstruction Method: SINGLE PARTICLE

EM Software:

Task	Software Package	Version
MODEL REFINEMENT	PHENIX	1.20.1
RECONSTRUCTION	cryoSPARC	4.1

Structure Validation

View Full Validation Report

View more in-depth experimental data

Entry History

& Funding Information

Deposition Data

Released Date: 2025-11-26

Deposition Author(s):

Funding Organization	Location	Grant Number
Carl Trygger Foundation	Sweden	CTS 21:1630

Revision History (Full details and data files)

Version 1.0: 2025-11-26
Type: Initial release
